RisingLCD outdoor high temperature resistant industrial-grade liquid crystal module, industrial liquid crystal display, derived from the backlight of industrial-grade liquid crystal panel and industrial-grade optical materials.
Brand:
Risinglcd
Model name:
RS430ENT-N30
Screen size:
43"
Screen type:
LCD Module
Resolution:
1920*1080 / 3840(RGB)×2160
Brightness (cd/m²):
1000 to 3000
RisingLCD outdoor high temperature resistant industrial-grade liquid crystal module, industrial liquid crystal display, using LG industrial-grade liquid crystal panel.
Advantages of RisingLCD industrial-grade LCD module:
1. Adopt LG industrial-grade LCD panel;
2. Aluminum alloy structure design;
3, 120 degrees Celsius optical materials;
4. Matrix LED backlight design;
5, industrial-grade backlight driver motherboard;
6, automatic, knob, pwm and more brightness adjustment methods;
7, Support long-term supply system;
8 or 7-day fast response mechanism；
9, automatically dimming backlight driver motherboard.
Techspecs:
Items | Specification | Note |
Panel Brand | RisingLCD | |
Diagonal Size | 43" | |
Panel Type | a-Si TFT-Module | LG/BOE |
Resolution | 1920×1080 / 3840 × 2160 (RGB) | |
Pixel Format | RGB Vertical Stripe | |
Display Area | 941.18×529.41mm (H×V) | |
Outline Size: | 963.6×567.9×40mm (H×V×D) | |
Surface | Antiglare (Haze 1%), Hard coating (2H). | |
Brightness | 500 to 3000 cd/m² (Typ.) | |
Contrast Ratio | 1300:1 (Typ.) (TM) | |
waterproof level | / | |
Protection level | / | |
Support Color | 1.67B 100% NTSC | |
Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | |
Display Mode | IPS, Normally Black, Transmissive . | |
Response Time | 5 (Typ.)(G to G); 8 (Typ.)(MPRT). | |
Lamp Type | WLED , 50K hours , With LED Driver | |
Frequency: | 60Hz | |
Panel Weight | 11Kgs (Typ./Max.) | |
Application | ||
Signal Interface | LVDS | |
Input Voltage: | 24V ,110 to 260V (Typ.). | |
Operating Temp. | -30 ~ 110 °C | |
Storage Temp. | -30 ~ 110 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
