Risingstar specilize in the outdoor and high brightness LCD products, our factory have our own RD department, so we can customize the products from its outside design to the outdoor brightness and waterproof system based on the customers requests. Competitive price, fast delivery, and high quality!
Risingstar specilize in the outdoor and high brightness LCD products, our factory have our own RD department, so we can customize the products from its outside design to the outdoor brightness and waterproof system based on the customers requests. Competitive price, fast delivery, and high quality!
General Description
AUO 21.5 inch high brightness LCD panel is specilized for a advertisiing player, due to its diagonal 21.5 inch versatile size, Risingstar customized LED backlight, the brightness can achieve 1000 nits, or even higher to 2000nits, this panel features 2K FHD resolution it can boast a vivid and clear image and image even in the directly sunlight. It is designed for versatilesize advertising player, this high brightness LCD panel is optimized for unique needs of these application, offering 24/7 running capabilit and superior performance over consumer tablet models.
Main Features:
AUO original TFT LCD panel
Ultra High resolution: 1920*1080
Wide view angel
High contrast ratio: 3000:1
Support Color: 16.7M
Brightness up to 1000 nits, 2000 nits.
Built-in Auto Light sensor
Long working lifes: 50000hours.
| Panel Model | Brand | Size | Composition | Resolution | Brightness | C/R | View Angle | Colors | Backlight | Interface |
| P215HVN01.0 | AUO | 21.5" | LCM | 1920×1080 | 300-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| M215HTN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 85/85/80/80 | 16.7M | WLED | LVDS |
| G215HAN01.0 | AUO | 21.5" | LCM | 1920×1080 | 400-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.101 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.001 | AUO | 21.5" | LCM | 1920×1080 | 300-2500 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HAN01.2 | AUO | 21.5" | LCM | 1920×1080 | 350-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| P215HAN02.0 | AUO | 21.5" | LCM | 1920×1080 | 1500-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN05.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.000 | AUO | 21.5" | LCM | 1920×1080 | 300-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN01.1 CELL | AUO | 21.5" | CELL | 1920×1080 | 300-2000 | 3000:1 | 89/89/85/85 | 16.7M | No B/L | LVDS |
| G215HAN01.201 | AUO | 21.5" | LCM | 1920×1080 | 300-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| P215HVN01.2 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.3 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HAN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | |
| G215HAN01.501 | AUO | 21.5" | LCM | 1920×1080 | 500-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.100 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN01.0 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| M215HTN01.3 | AUO | 21.5" | LCM | 1920×1080 | 200-2000 | 6000:1 | 45/45/20/45 | 16.7M | WLED | LVDS |
| M215HAN01.3 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| M215HAN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN05.0 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| Factory Item No | RS215ENT-N10 |
| Panel Brand | AUO/BOE/LG new brand display |
| Panel Model | T215HVN01.2 |
| Size | 21.5 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution: | 1920(RGB)×1080 [FHD] 102PPI |
| Pixel Format | RGB Horizontal Stripe |
| Display Area | 476.64 × 268.11 mm (H×V) |
| Surface Treatment | Antiglare, Hard coating (3H) |
| Brightness | 1000cd/m² RisingLCD customized |
| Constrast Ratio. | 3000:1 |
| Aspect Ratio: | 16:9 |
| View Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Model | TN, Normally Black, Transmissive |
| Response Time | 13/5 (Typ.)(Tr/Td) |
| Display Color | 16.7B 72% NTSC |
| Backlight | WLED , 50K hours , W/O LED Driver |
| Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Panel Weight | 1.8KGS (Typ./Max.) |
| Frame Rate | 60Hz |
| Working Temperature | 0 ~ 50 ° |
| Storage Temperature | -20 ~ 60 °C |
Risingstar specilize in the outdoor and high brightness LCD products, our factory have our own RD department, so we can customize the products from its outside design to the outdoor brightness and waterproof system based on the customers requests. Competitive price, fast delivery, and high quality!
General Description
AUO 21.5 inch high brightness LCD panel is specilized for a advertisiing player, due to its diagonal 21.5 inch versatile size, Risingstar customized LED backlight, the brightness can achieve 1000 nits, or even higher to 2000nits, this panel features 2K FHD resolution it can boast a vivid and clear image and image even in the directly sunlight. It is designed for versatilesize advertising player, this high brightness LCD panel is optimized for unique needs of these application, offering 24/7 running capabilit and superior performance over consumer tablet models.
Main Features:
AUO original TFT LCD panel
Ultra High resolution: 1920*1080
Wide view angel
High contrast ratio: 3000:1
Support Color: 16.7M
Brightness up to 1000 nits, 2000 nits.
Built-in Auto Light sensor
Long working lifes: 50000hours.
| Panel Model | Brand | Size | Composition | Resolution | Brightness | C/R | View Angle | Colors | Backlight | Interface |
| P215HVN01.0 | AUO | 21.5" | LCM | 1920×1080 | 300-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| M215HTN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 85/85/80/80 | 16.7M | WLED | LVDS |
| G215HAN01.0 | AUO | 21.5" | LCM | 1920×1080 | 400-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.101 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.001 | AUO | 21.5" | LCM | 1920×1080 | 300-2500 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HAN01.2 | AUO | 21.5" | LCM | 1920×1080 | 350-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| P215HAN02.0 | AUO | 21.5" | LCM | 1920×1080 | 1500-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN05.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.000 | AUO | 21.5" | LCM | 1920×1080 | 300-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN01.1 CELL | AUO | 21.5" | CELL | 1920×1080 | 300-2000 | 3000:1 | 89/89/85/85 | 16.7M | No B/L | LVDS |
| G215HAN01.201 | AUO | 21.5" | LCM | 1920×1080 | 300-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| P215HVN01.2 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.3 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HAN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | |
| G215HAN01.501 | AUO | 21.5" | LCM | 1920×1080 | 500-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| G215HVN01.100 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 5000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN01.0 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| M215HTN01.3 | AUO | 21.5" | LCM | 1920×1080 | 200-2000 | 6000:1 | 45/45/20/45 | 16.7M | WLED | LVDS |
| M215HAN01.3 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| M215HAN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 1000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN05.0 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
| T215HVN01.1 | AUO | 21.5" | LCM | 1920×1080 | 250-2000 | 3000:1 | 89/89/89/89 | 16.7M | WLED | LVDS |
