32 Inch Waterproof High Brightness LCD Monitor – Engineered for Demanding Outdoor Environments
Designed to perform flawlessly in extreme outdoor conditions, the 32-inch waterproof high brightness LCD monitor from RisingStar is a professional-grade display solution engineered for reliability, visibility, and longevity. This industrial LCD monitor integrates cutting-edge display technology with a robust, weatherproof construction, making it ideal for applications such as outdoor kiosks, EV charging stations, transportation hubs, marine systems, and digital signage in high ambient light environments.
High Brightness up to 3000–5000 nits: Delivers crystal-clear visibility even under direct sunlight, ensuring content remains vibrant and legible in any lighting condition.
Full IP65/IP66 Waterproof Enclosure: Built to withstand rain, dust, humidity, and harsh environmental elements. Ideal for year-round outdoor operation.
1920x1080 Full HD Resolution: Provides sharp image clarity with true-to-life color rendering for both static and dynamic content.
Advanced Anti-Reflective & Anti-UV Coating: Reduces glare and prevents screen degradation from prolonged sun exposure.
Industrial-Grade Components: Designed with high-reliability power systems, fanless heat dissipation, and 24/7 operation capability, ensuring over 50,000 hours of maintenance-free service.
Wide Operating Temperature Range (-30°C to +60°C): Rigorously tested to perform in extreme cold and heat, suitable for diverse geographic locations.
Flexible Mounting Options: Supports VESA and custom mounting solutions for seamless integration into various outdoor enclosures and environments.
This 32-inch waterproof high brightness LCD monitor is ideal for:
Public transportation displays (bus stops, train platforms, passenger information systems)
Smart city terminals and interactive kiosks
Petrol stations and EV charging point displays
Outdoor advertising and retail signage
Marine and navigation displays
With over a decade of expertise in industrial and outdoor display engineering, RisingStar is trusted by global OEMs and system integrators. Our monitors are manufactured under strict quality controls and adhere to international standards including CE, FCC, and RoHS.
The 32-inch waterproof high brightness LCD monitor is not just a screen—it’s a mission-critical visual communication tool built for durability, performance, and visual excellence.
32 Inch UHD a-Si TFT-LCD Panel – High-Resolution Display with Wide Viewing Angle and Industrial Reliability
| Item | Specification |
|---|---|
| Panel Size | 32.0 inches |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 3840 (RGB) × 2160 (UHD), 139 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Area | 697.306(W) × 392.234(H) mm |
| Outline Dimensions | 709.2(W) × 405.48(H) × 14.2(D) mm |
| Surface Treatment | Matte (Haze 25%), Hard Coating (3H) |
| Brightness (Typ.) | 500 to 5000nits |
| Contrast Ratio (Typ.) | 1300:1 (TM) |
| Viewing Angle (CR≥10) | 89°/89°/89°/89° (Left/Right/Up/Down) |
| Display Mode | IPS, Normally Black, Transmissive |
| Supported IPS Technologies | AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich |
| Response Time (Typ.) | 14 ms (G to G) |
| Display Colors | 1.07 Billion, 99% sRGB coverage |
| Backlight Type | 17S4P WLED, 30,000 Hours Lifetime, Driver Not Included |
| Refresh Rate | 60Hz Native 120Hz (via MEMC) 240Hz (via MEMC circuit, 60Hz input) |
| Touch Screen | None |
| Panel Weight | 4.52 / 4.75 kg (Typical / Max) |
| Application Fields | Computer Monitors, Industrial Displays |
| Signal Interface | eDP (4 Lanes), HBR2 (5.4 Gbps/lane), 30 pins, Terminal |
| Drive Voltage (Typ.) | 10.0V |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Item | Specification |
|---|---|
| Panel Size | 32.0 inches |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 3840 (RGB) × 2160 (UHD), 139 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Area | 697.306(W) × 392.234(H) mm |
| Outline Dimensions | 709.2(W) × 405.48(H) × 14.2(D) mm |
| Surface Treatment | Matte (Haze 25%), Hard Coating (3H) |
| Brightness (Typ.) | 500 to 5000nits |
| Contrast Ratio (Typ.) | 1300:1 (TM) |
| Viewing Angle (CR≥10) | 89°/89°/89°/89° (Left/Right/Up/Down) |
| Display Mode | IPS, Normally Black, Transmissive |
| Supported IPS Technologies | AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich |
| Response Time (Typ.) | 14 ms (G to G) |
| Display Colors | 1.07 Billion, 99% sRGB coverage |
| Backlight Type | 17S4P WLED, 30,000 Hours Lifetime, Driver Not Included |
| Refresh Rate | 60Hz Native 120Hz (via MEMC) 240Hz (via MEMC circuit, 60Hz input) |
| Touch Screen | None |
| Panel Weight | 4.52 / 4.75 kg (Typical / Max) |
| Application Fields | Computer Monitors, Industrial Displays |
| Signal Interface | eDP (4 Lanes), HBR2 (5.4 Gbps/lane), 30 pins, Terminal |
| Drive Voltage (Typ.) | 10.0V |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
32 Inch Waterproof High Brightness LCD Monitor – Engineered for Demanding Outdoor Environments
Designed to perform flawlessly in extreme outdoor conditions, the 32-inch waterproof high brightness LCD monitor from RisingStar is a professional-grade display solution engineered for reliability, visibility, and longevity. This industrial LCD monitor integrates cutting-edge display technology with a robust, weatherproof construction, making it ideal for applications such as outdoor kiosks, EV charging stations, transportation hubs, marine systems, and digital signage in high ambient light environments.
High Brightness up to 3000–5000 nits: Delivers crystal-clear visibility even under direct sunlight, ensuring content remains vibrant and legible in any lighting condition.
Full IP65/IP66 Waterproof Enclosure: Built to withstand rain, dust, humidity, and harsh environmental elements. Ideal for year-round outdoor operation.
1920x1080 Full HD Resolution: Provides sharp image clarity with true-to-life color rendering for both static and dynamic content.
Advanced Anti-Reflective & Anti-UV Coating: Reduces glare and prevents screen degradation from prolonged sun exposure.
Industrial-Grade Components: Designed with high-reliability power systems, fanless heat dissipation, and 24/7 operation capability, ensuring over 50,000 hours of maintenance-free service.
Wide Operating Temperature Range (-30°C to +60°C): Rigorously tested to perform in extreme cold and heat, suitable for diverse geographic locations.
Flexible Mounting Options: Supports VESA and custom mounting solutions for seamless integration into various outdoor enclosures and environments.
This 32-inch waterproof high brightness LCD monitor is ideal for:
Public transportation displays (bus stops, train platforms, passenger information systems)
Smart city terminals and interactive kiosks
Petrol stations and EV charging point displays
Outdoor advertising and retail signage
Marine and navigation displays
With over a decade of expertise in industrial and outdoor display engineering, RisingStar is trusted by global OEMs and system integrators. Our monitors are manufactured under strict quality controls and adhere to international standards including CE, FCC, and RoHS.
The 32-inch waterproof high brightness LCD monitor is not just a screen—it’s a mission-critical visual communication tool built for durability, performance, and visual excellence.
32 Inch UHD a-Si TFT-LCD Panel – High-Resolution Display with Wide Viewing Angle and Industrial Reliability
| Item | Specification |
|---|---|
| Panel Size | 32.0 inches |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 3840 (RGB) × 2160 (UHD), 139 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Area | 697.306(W) × 392.234(H) mm |
| Outline Dimensions | 709.2(W) × 405.48(H) × 14.2(D) mm |
| Surface Treatment | Matte (Haze 25%), Hard Coating (3H) |
| Brightness (Typ.) | 500 to 5000nits |
| Contrast Ratio (Typ.) | 1300:1 (TM) |
| Viewing Angle (CR≥10) | 89°/89°/89°/89° (Left/Right/Up/Down) |
| Display Mode | IPS, Normally Black, Transmissive |
| Supported IPS Technologies | AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich |
| Response Time (Typ.) | 14 ms (G to G) |
| Display Colors | 1.07 Billion, 99% sRGB coverage |
| Backlight Type | 17S4P WLED, 30,000 Hours Lifetime, Driver Not Included |
| Refresh Rate | 60Hz Native 120Hz (via MEMC) 240Hz (via MEMC circuit, 60Hz input) |
| Touch Screen | None |
| Panel Weight | 4.52 / 4.75 kg (Typical / Max) |
| Application Fields | Computer Monitors, Industrial Displays |
| Signal Interface | eDP (4 Lanes), HBR2 (5.4 Gbps/lane), 30 pins, Terminal |
| Drive Voltage (Typ.) | 10.0V |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
