RisingLCD 15 inch sunlight readable LCD panel is usually used for any embedded systems, industrial device, security and hand-held equipment which requires display in high quality and outdoor application that usualled used in the directly sunlight.
A good sunlight readable display is typically considered to be an LCD with 1000 nits brightness , RisingLCD RS150HAN-GE15 can achieve 1500 nits high brightness, can be clearly read even in the direct sunlight, this 15inch sunlight readable LCD panel screen is with led driver, and built in with controller IC, it supports LVDS interface, high brightness 1,500 nits, it is suitable for outdoor application that are used in the directly sunlight.
RS150HAN-GE15 is a Wide Temperature，sunlight readable，1024*768 TFT LCD panel, WLED Backlight，Life ≥ 50K hours，With LED Driver，with LVDS interface.
15 inch sunlight readable TFT LCD panel, 1500nits, LED Backlight 1024x768
High Brightness 1500 nits
Wide Operating Temp. -30 ~80 °C
With LED driver
BL MTBF: 50,000 hours
The 15 inch sunlight readable LCD monitor is often used for any embedded systems, industrial device, security and hand-held equipment which requires display in high quality and outdoor application.
15 inch Sunlight readable tft display module introduction:
TFT LCD display 15 inch is a color sunlight readable tft lcd display panel which is made with 1024RGBx768,XGA resolution. Each pixel is divided into Red, Green and Blue sub-pixels and dots, which are arranged in vertical stripes. This tft display is only 15 inch in diagonal, packed with RGB pixels, for making very small high-density displays.
The sunlight readable 15 inch tft lcd panel RS150HAN-GE15 is composed of a TFT-LCD panel, driver IC, FPC, a backlight unit.
|Screen Diagonal||15 inch|
|Active Area||304.128(W)×228.096(H) mm|
|Pixels||1024(RGB)×768, XGA, 85PPI|
|Physical Size||326.5(W)×253.5(H)×12(D) mm|
|Pixel Arrangement||R.G.B. Vertical Stripe|
|Display Mode||a-Si TFT-LCD, LCM|
|White Luminance ( Center )||1500 cd/m2 (Typ.) [cd/m2 ]|
|Contrast Ratio||700:1 (Typ.)|
|Optical Response Time||8/17 (Typ.)(Tr/Td) ms|
|Nominal Input Voltage||3.3V (Typ.)|
|Viewing Angle||80/80/80/60 (Typ.)(CR≥10)|
|Interface Type||LVDS (1 ch, 6/8-bit) , 20 pins Connector|
|Support Color||16.7M/262K, 40% NTSC|
|Surface Treatment||Hard coating (3H), haze 25%|
|RoHS Compliance||RoHS Compliance|
|Temperature Range||-30 ~80 °C|
|Storage (Non-Operating)||-40 ~ 80 °C|
Ask a quote for the latest price and one of our team members will respond as soon as possible.
