50 inch outdoor digital signage advertising screen, standard design, waterproof, fully sealed, maintenance free, ultra-thin, suitable for outdoor digital sign advertising display, such as bus stop information display, public information publicity, charging pile display, store commercial window advertising display, outdoor media advertising, smart city information release, smart community information release, Smart campus information release, etc
品牌：RISINGLCD 型号名称：RS550ENT-N15
Brand: risinglcd Model name: rs550ent-n15
屏幕尺寸：50" 屏幕类型：液晶模组,a-Si TFT-LCD
Screen size: 50“ Screen type: LCD module, a-Si TFT-LCD
分辨率：3840(RGB)×2160 像素配置： RGB垂直条状
Resolution: 3840 (RGB) × 2160 pixel configuration: RGB vertical bar
显示尺寸：1095.40×616.86 mm (H×V) 外观尺寸：121.5×733.8×950 mm (H×V×D)
Display size: 1095.40 × 616.86 mm (H × V) Appearance dimension: 121.5 × seven hundred and thirty-three point eight × 950 mm (H × V × D)
可视尺寸：1110.5×633.8 mm (H×V) 表面处理：雾面，Hard coating (3H)
Visual size: 1110.5 × 633.8 mm (H × V) Surface treatment: foggy surface, hard coating (3H)
亮度(cd/m²)：2500 对 比 度：1500 : 1
Brightness (CD / M) ²)： 2500 contrast: 1500: 1
最佳角度：全视角 光学模式：AHVA，常黑显示，透射式
Best angle: full view Optical mode: ahva, normally black display, transmissive
可视角度：89/89/89/89 响应速度：25 ms
Viewing angle: 89 / 89 / 89 / 89 Response speed: 25 ms
颜色数量：16.7M , 72% NTSC背光类型：4 strings×2CN WLED , 50K小时 , 无驱动
Number of colors: 16.7M, 72% NTSC backlight type: 4 strings × 2cn WLED, 50K hours, no drive
屏幕重量：2.10Kgs 适 用 于：数字标牌 户外高亮
Screen weight: 2.10kgs Applicable to: outdoor highlight of digital signs
刷新频率：60Hz
Refresh frequency: 60Hz
信号系统：LVDS (2 ch, 8-bit) , 端子 , 30 pins
Signal system: LVDS (2 CH, 8-bit), terminal, 30 pins
供应电压：5.0V (Typ.)
Supply voltage: 5.0V (typ.)
最大额定：存储温度: -20 ~ 60 °C 工作温度: -10 ~ 50 °C
Maximum rated storage temperature: - 20 ~ 60 ° C working temperature: - 10 ~ 50 ° C
购买请联系risingstarlcd11@Foxmail.com
Please contact for purchase risingstarlcd11@Foxmail.com
Screen size: 50“ Screen type: LCD module, a-Si TFT-LCD
分辨率：3840(RGB)×2160 像素配置： RGB垂直条状
Resolution: 3840 (RGB) × 2160 pixel configuration: RGB vertical bar
显示尺寸：1095.40×616.86 mm (H×V) 外观尺寸：121.5×733.8×950 mm (H×V×D)
Display size: 1095.40 × 616.86 mm (H × V) Appearance dimension: 121.5 × seven hundred and thirty-three point eight × 950 mm (H × V × D)
可视尺寸：1110.5×633.8 mm (H×V) 表面处理：雾面，Hard coating (3H)
Visual size: 1110.5 × 633.8 mm (H × V) Surface treatment: foggy surface, hard coating (3H)
亮度(cd/m²)：2500 对 比 度：1500 : 1
Brightness (CD / M) ²)： 2500 contrast: 1500: 1
最佳角度：全视角 光学模式：AHVA，常黑显示，透射式
Best angle: full view Optical mode: ahva, normally black display, transmissive
可视角度：89/89/89/89 响应速度：25 ms
Viewing angle: 89 / 89 / 89 / 89 Response speed: 25 ms
颜色数量：16.7M , 72% NTSC背光类型：4 strings×2CN WLED , 50K小时 , 无驱动
Number of colors: 16.7M, 72% NTSC backlight type: 4 strings × 2cn WLED, 50K hours, no drive
屏幕重量：2.10Kgs 适 用 于：数字标牌 户外高亮
Screen weight: 2.10kgs Applicable to: outdoor highlight of digital signs
刷新频率：60Hz
Refresh frequency: 60Hz
信号系统：LVDS (2 ch, 8-bit) , 端子 , 30 pins
Signal system: LVDS (2 CH, 8-bit), terminal, 30 pins
供应电压：5.0V (Typ.)
Supply voltage: 5.0V (typ.)
最大额定：存储温度: -20 ~ 60 °C 工作温度: -10 ~ 50 °C
Maximum rated storage temperature: - 20 ~ 60 ° C working temperature: - 10 ~ 50 ° C
