Panel Brand:
BOE
Panel NO:
DV750QUB-R01
Screen size:
75"
Screen type:
LCD Monitor
Resolution:
3840*2160 (UHD) 59PPI
Brightness (cd/m²):
5000
General Description
RisingLCD RS750ENT-N50 is a 65 inch outdoor window facing display that adopts BOE industrial grade OC, with 3840*2160 ultra high resolution, and 16:9 aspect ration, 1200:1 contrast ratio, its brightness can achieve 5000nits after RisingLCD re design the LED back light, -30 ~ 80 °C wide operating temperature that is ideal for industries such as gaming, medical, military/defense, retail, automation/industrial, and gransportation.
Main Features:
BOE original Industrial LCD panel
Ultra High resolution: 3840*2160
Brightness up to 5000 nits
Wide operating temperature: -30 ~ 80 °C
Blackening Defect free
AR Glass, reduce reflectioin effect.
Built-in Auto Light sensor
Interface: HDMI(2)/DP/DVI-D/RJ45/RS232C/USB
Industrial operating temperature range, this outdoor window facing display can operate in a stable and failure-free way for a long period within wide range of tepmerature -30 ~ 80 °C, thanks to such option, it maybe successfully applied in transportation and automotive industry. Most residential and commercial display will blacken or result in isotropic failure with the display overheats for a long period, RS650ENT-N30 industrial window facing display is equipped with a high-temperature BOE LCD panel ( DV750QUB-R01) that can withstand the themperatures up to 110˚C (230°F) without blackening – crucial for direct sunlight applications.
Outstanding visibility,
Billiant and bright, the industrial outdoor window facing series process powerful brightness of 3000nits, message remain clear and bright even in the outdoor direct sunlight in a store front and along with the extra wide 178° viewing angle is a perfect fit for shoppers, store, employees or visitors that will view Window Facing displays from diverse angles while passing by.
4K Ultra HD
With 4K 3840*2160 ultra high resolution, RisingLCD RS750ENT-N50 window facing diisplay can offer the 4K Ultra HD picture that ensures perfect colour and rich details in all possible broadcasting surroundings, ranging from shops, to restaurants and office buildings.
Auto brightness control
Different external lighting condition requires different brightness leverls, an onboard light sensor that built-in our outdoor window facing display measures the ambient light in the area and automatically adjust the image light accordkingly, offer a best experience to the viewer, and also can save the engery cost, reduce the heat and extends the life of the screen.
This industrial outdoor window facing displays series are optimized for customers with its VESA mounting holes and customized with different brightness to meet differents business needs, from indoor 500 nits to outdoor 3000nits. And based on the industry and application, this industrial outdoor window facing display can mount to wall, hang to celling or floor standing)
OEM and ODM are welcomed!
RisingLCD is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, outdoor and indoor digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingLCD is your best choice!
Hot Tags: BOE 65 inch industrial window facing display, BOE 32 inch industrial floor standing dispaly, 55 inch high brightness window facing display, lg, 21.5inch lg high brightness display, 50 inch touch screen kiosk, 55 inch touch screen display, wall mounted advertising window facing player, dual side floor standing window facing display, dual sided display, floor standing, 43" window facing display, sunlight screen 2500 nits lcd panel, China, factory, cheap, price, customized, quotation, 65 Inches Highlight LCD, 4000 cd/m² LCD Screen, 86" high brightness display, 21.5 LCD Strip Screen 55 inch P550HVN06.4 high brightness lcd display
| Factory Model No: | RS750ENT-N50 |
| Panel Brand | BOE Display |
| Panel No.: | DV750QUB-R01 |
| Screen Size | 75" |
| Panel Technology | IPS, M+ (WRGB) |
| Active Area(mm) | 1649.66*927.936 (H×V)mm |
| Panel Type. | a-Si TFT-LCD, |
| Aspect Ratio | 16:09 |
| Native Resolution | 3840*2160 (UHD) 59PPI |
| Refresh Rate | 60Hz |
| Brightness | 5000nit (Typ, w/ Glass) |
| Contrast Ratio | 1200:1 (Typ) |
| Dynamic CR | 500,000:1 |
| Color gamut | NTSC 72% |
| Viewing Angle (H x V) | 178 x 178 |
| Support Color: | 1.07M , 89% NTSC |
| Response Time | 8 (Typ.) (G to G)ms |
| Surface Treatment (Haze) | Hard coating (3H), Reflection 1.0% (Max.) |
| Transmittance: | 5.5% (Typ.) (with Polarizer) |
| Life time | 50,000 Hrs (Typ) |
| Operation Hours (Hours/Day) | 24/7 |
| Operating Temperature: | -30 ~ 80 °C |
| Storage Temperature: | -30 ~ 80 °C |
| Portrait / Landscape | Yes / Yes |
| QWP (Quarter Wave Plate) | Yes (Apply on glass) |
| Housing | Aluminum |
| Jack interface input | HDMI (2), , RS232C IN (4pin phone jack), RJ45(LAN), IR IN, USB2.0 Type A (1) |
| Jack interface output | DP Out (Input DP/HDMI), Externel Speaker Out (L/R, 10W+10W), RS232C OUT |
| Net work support | LAN/WLAN/3G/4G/5G network. |
