Brand:
RisingStar
Model name:
RS215ENT-NE10
Screen size:
21.5"
Screen type:
high brightness
Resolution:
1920 (RGB) × 1080, FHD, 102 PPI
Brightness (cd/m²):
Brightness can be customized from 500 to 2500.
21.5" High Brightness LCD Display - All Models (RisingStar)
Normal Series (E Series)
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS215ENT-NE05 | 500 | 1920 × 1080 |
| RS215ENT-NE10 | 1000 | 1920 × 1080 |
| RS215ENT-NE15 | 1500 | 1920 × 1080 |
Normal Series (D Series)
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS215ENT-ND20 | 2000 | 1920 × 1080 |
| RS215ENT-ND25 | 2500 | 1920 × 1080 |
Full HD resolution with wide viewing angles
High brightness options: 500 nits / 1500 nits
AHVA (IPS-equivalent) optical mode, normally black
72% NTSC color performance
120Hz/240Hz optional with built-in MEMC
Long-lifetime WLED backlight (50,000 hrs)
Ideal for industrial equipment and medical imaging displays
| Item | Description |
|---|---|
| Panel Size | 21.5 inches |
| Panel Type | a-Si TFT-LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 102 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 476.064 (W) × 267.786 (H) mm |
| Outline View Area | 479.8 (W) × 271.3 (H) mm |
| Surface Treatment | Anti-glare, Hard Coating (3H) |
| Brightness | 500 nits / 2500 nits |
| Contrast Ratio | 1000:1 (Typ., Transmission) |
| Viewing Angle | 89/89/89/89 (Typ., CR≥10) – L/R/U/D |
| Optical Mode | AHVA (IPS-type), Normally Black, Transmissive |
| Response Time | 12/10 ms (Tr/Td, Typ.) |
| Color Depth | 16.7M colors, 72% NTSC |
| Backlight | 12S4P WLED, 50,000 hours, driver not included |
| Weight | 1.8 kg (Typ.) |
| Refresh Rate | 60Hz |
| High-Rate Options | 120Hz (60Hz input with MEMC) / 120Hz+120Hz / 240Hz (60Hz input) |
| Signal Interface | LVDS (2-ch, 8-bit), 30-pin connector |
| Supply Voltage | 5.0V (Typ.) |
| Operating Temperature | 0 ~ 50°C |
| Storage Temperature | 0 ~ 50°C |
This 21.5-inch high-performance LCD module is designed for industrial environments and precision medical imaging systems. With up to 1500-nit high brightness, wide viewing angles, and a robust AHVA (IPS-equivalent) optical mode, it delivers stable visibility for:
Industrial HMIs and control panels
Test & measurement instrumentation
Navigation systems and marine displays
Factory automation and process monitoring
High-brightness indoor signage and kiosk terminals
Its extended temperature range, long backlight life, and optional 120Hz/240Hz motion enhancement make it suitable for demanding 24/7 operation in professional environments.
