Brand:
RisingStar
Model name:
RS270ENT-NE10
Screen size:
27"
Screen type:
high brightness
Resolution:
1920(RGB) × 1080, FHD, 81 PPI
Brightness (cd/m²):
Brightness can be customized from 500 to 2500.
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS270ENT-NE05 | 500 | 1920 × 1080 |
| RS270ENT-NE10 | 1000 | 1920 × 1080 |
| RS270ENT-NE15 | 1500 | 1920 × 1080 |
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS270ENT-ND20 | 2000 | 1920 × 1080 |
| RS270ENT-ND25 | 2500 | 1920 × 1080 |
| Item | Description |
|---|---|
| Panel Size | 27.0 inches |
| Panel Type | a-Si TFT-LCD Module |
| Resolution | 1920(RGB) × 1080, FHD, 81 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 597.6(W) × 336.15(H) mm |
| Viewing Area | 601.6(W) × 340.15(H) mm |
| Surface Treatment | Matte, Hard Coating (3H) |
| Brightness | 500 ~ 2500 nits (Typ.) |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ., CR≥10) (L/R/U/D) |
| Display Mode | AMVA, Normally Black, Transmissive |
| Panel Technology Notes | IPS Type: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich VA Type: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Response Time | 7 / 5 ms (Typ., Tr/Td) |
| Display Colors | 16.7M, 72% NTSC |
| Backlight Type | 15S4P WLED, 40,000 hrs, Driver Not Included |
| Refresh Rate | 75Hz 120Hz (60Hz input) with built-in MEMC 120Hz + 120Hz (Panel + Backlight) 240Hz (60Hz input) |
| Panel Weight | 2.18 kg (Typ.) |
| Application | Desktop Monitor |
| Signal Interface | LVDS (2 ch, 8-bit), 30-pin |
| Driving Voltage | 5.0V (Typ.) |
| Operating Temp. | 0 ~ 50°C |
| Storage Temp. | 0 ~ 50°C |
This 27-inch high-performance LCD panel is suitable for:
Computer Monitors / Office Displays
Professional Workstation Screens
Gaming Monitors (with MEMC / high refresh compatibility)
Industrial PCs and Control Terminals
Medical Display Equipment
Business / Education Display Terminals
