Brand:
RisingStar
Model name:
RS860FNX01D01
Screen size:
86 inch
Screen type:
open frame display
Resolution:
1920(RGB)×1080
Brightness (cd/m²):
5000
High brightness 500 nits
LED Backlight
Wide Viewing Angle of 178°(H), 178°(V)
Wide Operation Temperature (0˚C ~ 50˚C)
LCD Blacking Defect Free
Low Power Consumption
BL MTBF: 50,000 hours
| Item | Description |
|---|---|
| Model Name | RS860FNX01D01 |
| Screen Size | 86" |
| Display Area (mm) | 1895.04(H) × 1065.96(V) |
| Brightness | 500 cd/m² |
| Resolution | 3480 × 2160 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1000:1 |
| Pixel Pitch (mm) | 0.4935(H) × 0.4935(V) |
| Viewing Angle | 89/89/89/89 (Min.) (CR ≥ 10) |
| Color Saturation (NTSC) | 68% |
| Display Colors | 16.7M |
| Response Time (Typical) | 8 ms (Tr/Td) |
| Input Interface | USB ×1 / HDMI ×2 / AC IN ×1 |
| OSD Key | INPUT / MENU / VOL− / VOL+ / CH− / CH+ / POWER / IR Remote Control |
| Glass | N/A |
| Touch Type | N/A |
| Input Power | AC 200–240V |
| Power Consumption | TBD |
| Radiator System | N/A |
| Dimensions (mm) | 1930.04 × 1110.96 × 75.5 |
| Mounting | N/A |
| Weight (Net) | TBD |
| Operating Temperature | 0˚C ~ 50˚C |
| Storage Temperature | -10˚C ~ 60˚C |
| Item | Description |
|---|---|
| Model Name | RS860FNX01D01 |
| Screen Size | 86" |
| Display Area (mm) | 1895.04(H) × 1065.96(V) |
| Brightness | 5000 cd/m² |
| Resolution | 3480 × 2160 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1000:1 |
| Pixel Pitch (mm) | 0.4935(H) × 0.4935(V) |
| Viewing Angle | 89/89/89/89 (Min.) (CR ≥ 10) |
| Color Saturation (NTSC) | 68% |
| Display Colors | 16.7M |
| Response Time (Typical) | 8 ms (Tr/Td) |
| Input Interface | USB ×1 / HDMI ×2 / AC IN ×1 |
| OSD Key | INPUT / MENU / VOL− / VOL+ / CH− / CH+ / POWER / IR Remote Control |
| Glass | N/A |
| Touch Type | N/A |
| Input Power | AC 200–240V |
| Power Consumption | TBD |
| Radiator System | N/A |
| Dimensions (mm) | 1930.04 × 1110.96 × 75.5 |
| Mounting | N/A |
| Weight (Net) | TBD |
| Operating Temperature | 0˚C ~ 50˚C |
| Storage Temperature | -10˚C ~ 60˚C |
High brightness 500 nits
LED Backlight
Wide Viewing Angle of 178°(H), 178°(V)
Wide Operation Temperature (0˚C ~ 50˚C)
LCD Blacking Defect Free
Low Power Consumption
BL MTBF: 50,000 hours
| Item | Description |
|---|---|
| Model Name | RS860FNX01D01 |
| Screen Size | 86" |
| Display Area (mm) | 1895.04(H) × 1065.96(V) |
| Brightness | 500 cd/m² |
| Resolution | 3480 × 2160 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1000:1 |
| Pixel Pitch (mm) | 0.4935(H) × 0.4935(V) |
| Viewing Angle | 89/89/89/89 (Min.) (CR ≥ 10) |
| Color Saturation (NTSC) | 68% |
| Display Colors | 16.7M |
| Response Time (Typical) | 8 ms (Tr/Td) |
| Input Interface | USB ×1 / HDMI ×2 / AC IN ×1 |
| OSD Key | INPUT / MENU / VOL− / VOL+ / CH− / CH+ / POWER / IR Remote Control |
| Glass | N/A |
| Touch Type | N/A |
| Input Power | AC 200–240V |
| Power Consumption | TBD |
| Radiator System | N/A |
| Dimensions (mm) | 1930.04 × 1110.96 × 75.5 |
| Mounting | N/A |
| Weight (Net) | TBD |
| Operating Temperature | 0˚C ~ 50˚C |
| Storage Temperature | -10˚C ~ 60˚C |
