46" Industrial Ultra High Brightness LCD Display Panel
46" Industrial Ultra High Brightness LCD Display - All Models (RisingStar)
Industrial Series (D Series)
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS460ENT-GD20 | 2000 | 1920×1080 / 3840×2160 |
| RS460ENT-GD25 | 2500 | 1920×1080 / 3840×2160 |
| RS460ENT-GD30 | 3000 | 1920×1080 / 3840×2160 |
| RS460ENT-GD35 | 3500 | 1920×1080 / 3840×2160 |
| RS460ENT-GD40 | 4000 | 1920×1080 / 3840×2160 |
| RS460ENT-GD45 | 4500 | 1920×1080 / 3840×2160 |
| RS460ENT-GD50 | 5000 | 1920×1080 / 3840×2160 |
Specification
| Parameter | Specification |
|---|---|
| Panel Size | 46.0 inch |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920(RGB) × 1080, FHD, 47 PPI, RGB vertical stripe |
| Active Area (W×H) | 1018.08 × 572.67 mm |
| Visible Area (W×H) | 1024.5 × 579.1 mm |
| Brightness | 2000 ~ 5000 nits |
| Viewing Angle (Typ., CR≥10) | 85/85/85/85 (Left/Right/Up/Down) |
| Viewing Direction | Full View Angle |
| Display Colors | 16.7M / 1.07B, 72% NTSC |
| Refresh Rate | 60Hz 120Hz (60Hz input, built-in MEMC) 120Hz+120Hz (panel+backlight) 240Hz (60Hz input, built-in MEMC) |
| Weight (Typ.) | 11.0 kg |
| Surface Treatment | Anti-glare (Haze 28%) |
| Contrast Ratio (Typ., Transmissive) | 4000:1 |
| Operating Mode | AMVA3, normally black, transmissive IPS Hard Screen Series: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich VA Soft Screen Series: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Response Time (Typ., G to G) | 8 ms |
| Backlight Type | WLED, 50,000 hrs, with LED driver |
| Touch Screen | Optional |
| Application | Digital Signage, Outdoor High-Brightness Displays |
| Signal Interface | LVDS (2 ch, 8/10-bit), 51 pins, terminal |
| Driving Voltage (Typ.) | 12.0 V |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Explanation and Application
Explanation:This 46-inch a-Si TFT-LCD module offers full HD resolution with high brightness up to 5000 nits, making it suitable for both indoor and outdoor applications. The wide viewing angle ensures consistent image quality from all directions, while AMVA3 technology provides deep contrast (4000:1 typical) and vibrant colors (16.7M/1.07B colors, 72% NTSC). The panel supports multiple refresh rates including 120Hz and MEMC features for smoother motion display. Its anti-glare coating (Haze 28%) reduces reflections under bright sunlight. WLED backlight ensures long lifespan (50,000 hrs) and energy efficiency.
Applications:
Outdoor digital signage and advertising displays
High-brightness monitors for transportation hubs (bus stations, metro stations)
Information displays for retail or commercial areas
Interactive kiosks or touch-enabled displays
Industrial and professional visual solutions requiring wide viewing angles and high contrast
