23.8 inch QLED outdoor high brightness advertising display
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
RS238ENT-N05 is a 23.8 inch QLED outdoor advertising display is equipped with original LG panel no LM238WR2-SPE1 that characterizes a great resolution 3480(RGB)*2160 (UHD), and a high brightness of 540 cd/m², Constrast Ratio 4000:1. and work life can achieve above 50,000 hours after RisingLCD customized, the brightness can achieve 450-1500cd/m², this display is with quantum-dot technology, can display a vider range of colors than regular LED, they are widely applying for the advertising industry, LCD monitor, industrial equipment, TV monitor, outdoor advertising screen, game monitor.
With 4K QLED, this outdoor high brightness display are able to deliver up to 1500-nit brightness levels, the users can experience superior picture quality and optimized visibility for outdoor environment, perfect for meeting the demands of your business.
Due to the anti-reflection glass and wide view angle, this out door QLED display eliminates the air between the lcd panel and tempered glass, it helps to provide high brighness, lower reflection and high contrast ration display, and makes the images and contents clearer and richer even it is under the direct sunlight.
Thanks to the IPS technology, it does not produce image distortion and minimizes color shift when viewed from different angles, the IPS panel provides clear images and instantly optimizes screen color and brightness.
OEM and ODM are welcomed!
RisingLCD is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, outside and inside digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingLCD is your best choice!
| Item No: | RS238ENT-N05 |
| Panel Brand | LG |
| Panel Item | LM238WR2-SPE1 |
| Size | 23.8 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution: | 3840*2160 UHD 185PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 527.04*296.46(H*V)mm |
| Outline Size | 544.7*328.2*14.3(H*V*D)mm |
| Bezel Area | |
| Surface Treatment | Antiglare |
| Brightness | 540-1500cd/m² |
| Constrast Ratio. | 4000:1 |
| View Angle | 89/89/89/89(Min) |
| Display Model | IPS Normally Black, transmissive Display |
| Best View on | Symmetry |
| Response Time | 14 (Typ.)(G+G) ms |
| Display Color | 1.07B, 98% DCI-P3 |
| Backlight | WLED, 30K hours, With LED Driver |
| Touch Screen | Without |
| Panel Weight | 2.19/2.3Kgs (Typ.) |
| Frame Rate | 60Hz |
| Signal Interface | V-by-one 8 lane, 51pins connector |
| Input Voltage | 10v(Typ.) |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Current State: | In Production |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
