Specifications

Display Area941*529.4MM
Brightness3500 nits
Resolution1920*1080
Aspect Ratio16:9
Contrast Ratio1200:1
Response Time6/9 (Typ.)(Tr/Td) ms
Viewing Angle89/89/89/89 (Min.)(CR≥10)
BacklightDLED
Life Hourup to 50,000 hours
Smart DimmingSupport
Intelligent Temperature ControlSupport
Remote Control FunctionSupport
VideoHDMI, VGA
Input VoltageAC110V/220V,50/60HZ
Maximum Power188W
Shell MaterialSheet Metal
Product Size1044*632*123.6mm
Weight43 kg
IncludedAC Power Cable, Remote Control, Wall Mount
Operating EnvironmentOutdoor IP65
Operating Temp.-20-70°C
Motherboard TypeAndroid/PC/HD Driver Board (optional)
IO interfaceHDMI/VGA/DVI
AD BoardAndroid Mother Board, Computer Mother Board
Network TransmissionStandalone Mode、WIFI、3G、4G
Touch10 points touch, 20 points touch, Capacitive touch

RS430HNX05A01-bk is a 43-inch LCD display with 3,500 nits brightness, 1920×1080 resolution and 1200:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

Reliable Global Supplier of Outdoor IP65 Waterproof LCD Digital Displays

Durable screens built for all weather, delivering sharp visibility in rain, dust, or sunlight. Trusted worldwide for smart retail, transit hubs, and EV charging stations.

r

43-Inch Outdoor Waterproof LCD Digital Signage: Compact Powerhouse for High-Impact Visibility

Targeted Solutions for Real-World Needs:

Space-Smart Design

Slim profile and lightweight frame (IP65-rated) fit seamlessly into tight spaces—perfect for storefronts, transit shelters, or parking lot kiosks.

Energy-Efficient Clarity

1600 nits brightness with dynamic dimming cuts glare and power costs, ideal for 24/7 convenience stores or EV charging stations.

Zero-Hassle Maintenance

Corrosion-resistant glass and modular components withstand salt, dust, and UV exposure, slashing long-term ownership costs.

Trusted Where Precision Matters

From roadside advertising to smart city dashboards, we blend aerospace-grade aluminum frames with RoHS-compliant tech. Your vision, amplified—rain or shine.

w

Why Partner With Us?

1. Flexible Sizing: Break free from standard sizes—design displays that fit your space, from narrow storefronts to sprawling parking lots.

2. Extreme Weatherproofing: Built with corrosion-resistant alloy and anti-UV layers to survive storms, salt, and -20 ~ 70°C extremes.

3. Smart & Scalable: Integrate IoT sensors, touchscreens, or EV charging interfaces seamlessly.

4. End-to-End Service: From CAD mockups to on-site installation support—we handle it all.

5. Trusted by airports, smart cities, and global brands. CE/FCC/RoHS certified. Your vision, our precision—rain or shine.

y

Top grade LCD panel: Risingstar has ability making our own design LCD panel, and we purchase A and A+ level Open-cell from RisingStar and other famous liquid crystal glasses maker directly, this is the proof to make the high quality displays for each of our customers.

BOE, LG, AUO

Rugged and unique housing: This display has unqiue outershell, you can see the crave on the display is as sort of thermal dissipition design by our own design, this allowed the display dissiption heat without fan or A/C, to save the power consumption; it can be fully muted if you need mount it in some quiet place such like library, this also the reason why this outdoor display sometimes will mounted indoor by our customers.

back side of the 32inch fanless LCD display

High adaptability electronic: Risingstar has customers from all over the world, EU, US, Asia...using the right plug and adapt different voltage is the basic issue we should figure out for our customers, you do not need worry about this; the possibly OS for the display, we can offer both PC and Android to make you using easier; also the interfaces, HDMI/USB/VGA/DVI/DP/Type-C/RJ45 by your choice, our enegineer will help you found the most suitable motherboard.

Interfaces of the 32-inch outdoor fanless LCD display

Ultra wide viewing angle: Most of the Risingstar display is IPS screen, which has extremely high viewing angle could reach 178° for both horizontal and vertical direction.

Risingstar LCD always have ultra wide view angle

Multiple mounting type: for each display our engineer will reserved the mounting hole by your request, you can mounting it on the wall, ceiling, floor standing, hanging...whatever your choice, and our default mounting is VESA.

Risingstar all products and mounting types

43-inch window facing display series:

RS430LNX01P01, lower brightness but full waterproof indoor display, special product for low light environment such like Museum/Aquarium...

RS430MNX03D01, semi-outdoor and super slim design, the most highest integrated display we ever made...

RS430MNX01D01, classic design, the standard type of 43-inch window facing display

Product FAQs

  • It is rated at 3,500 nits (cd/m²) brightness.

  • It uses a 43-inch panel, 1920×1080 resolution, 1200:1 contrast ratio.

  • The operating temperature range is -20 °C to 70 °C.

  • Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

  • It adopts HDMI/VGA/DVI interface.

  • The power input requirement is AC110V/220V,50/60HZ.

  • The viewing angle is 89/89/89/89 (Min.)(CR≥10).

  • Yes. Rated at 3,500 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
