    Manufacturer RisingLCD model RS195ENT-NE10

    2021-10-21 15:06:24  News

    Resolution 1600 (RGB) x 900 HD + 94 ppi pixel permutation RGB Vertical strip < br / > the LCR Vertical Stripe: left right Vertical strip < br / > a Rectangle, square < br / > RGB Delta:

    RGB Vertical Stripe:

    RGB Vertical Stripe:

    RGBW Rectangle: Red green blue white square < BR />RG/BW PenTile: (Red green)(blue and white) Vertical stripes < BR />RG/BG PenTile: (red green)(blue and green) Vertical stripes < BR />RGBY Vertical Stripe: Red, green, blue and yellow


    Display area 432(horizontal)×239.76(vertical) mm Appearance size 452(horizontal)×263(vertical)× 11(thick) mm


    Open area 435.3(horizontal)×243.06(vertical) mm Surface treatment Haze (25%), Hard coating (3H)


    Display brightness 1000 CD /m² (Typ.) to ratio 1000:1 (Typ.) (transmission)


    6 O 'clock Response time 5 (Typ.)(Tr+Td) ms


    Viewing Angle 85/85/80/80 (Typ.)(CR10) Left/right/up/Down display mode TN, always white display, transmission < BR />IPS hard screen series: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich< BR />VA series: ASV, HVA, MVA, PVA, SVA, UV²A, VA


    Support 16.7m color, 72% NTSC light source type WLED [10S4P], 40K hours, no driver


    Weight 1.43/1.50Kgs (Typ./Max.) Application computer monitors


    Frame frequency 60Hz

    120Hz (60Hz input) : built-in MEMC circuit

    120Hz+120Hz: 120Hz panel +120Hz backlight

    240Hz (60Hz input) : built-in MEMC circuit touch technology without touch


    Port type 30 Pins LVDS (2 CH, 8-bit), terminal


    Voltage supply 5.0V (Typ.)


    Operating temperature: 0 ~ 50 °C; Storage temperature: -20 °C to 60 °C
