| Category | Specification |
|---|---|
| Panel Size | 19.5 inches |
| Panel Type | a-Si TFT-LCD, Cell Module |
| Resolution | 1920 (RGB) × 1080 (FHD), 112 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 434.88(W) × 238.68(H) mm |
| Viewing Area | 438.18 × 241.98 (H×V) mm |
| Brightness | 500–3000 nits |
| Recommended Viewing Direction | All View |
| Viewing Angle (CR≥10) | 85/85/85/85 (L/R/U/D) |
| Color Depth | 16.7M Colors, 72% NTSC |
| Weight | 1.66 ± 0.08 kg |
| Refresh Rate Options | 60Hz 120Hz (60Hz Input, with MEMC) 120Hz+120Hz (120Hz Panel + 120Hz Backlight) 240Hz (60Hz Input, with MEMC) |
| Surface Treatment | Anti-glare (Haze 25%), Hard Coating (3H) |
| Contrast Ratio | 3000:1 (Typ., Transmission) |
| Optical Mode | MVA, Normally Black, Transmissive IPS Series Supported: AAS/ADS/AHVA/FFS/HFS/HIS/IPS/New Mode2/PLS/SFT/Vistarich VA Series Supported: ASV/FSA/HVA/MVA/PVA/SVA/UV²A/VA |
| Response Time | 15/5 ms (Tr/Td), 25 ms (Gray-to-Gray) |
| Backlight System | WLED, 50,000 hours, Built-in LED Driver |
| Application | Industrial Use |
| Touch Function | No Touch |
| Signal Interface | LVDS (2-channel, 8-bit), 30-pin connector |
| Power Supply | 5.0V (Typ.) |
| Storage Temperature | –20 ~ 60 °C |
| Operating Temperature | 0 ~ 50 °C |
This 19.5-inch high-brightness LCD is ideal for a wide range of industrial and commercial display applications, including:
Industrial control terminals
Human–machine interface (HMI) systems
Factory automation equipment
Instrumentation displays
Kiosks & vending systems
Ticketing and payment terminals
Medical and diagnostic equipment
Transportation information terminals (PIS, control panels)
Outdoor/indoor high-brightness digital signage (with enclosure)
| Category | Specification |
|---|---|
| Panel Size | 19.5 inches |
| Panel Type | a-Si TFT-LCD, Cell Module |
| Resolution | 1920 (RGB) × 1080 (FHD), 112 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 434.88(W) × 238.68(H) mm |
| Viewing Area | 438.18 × 241.98 (H×V) mm |
| Brightness | 500–3000 nits |
| Recommended Viewing Direction | All View |
| Viewing Angle (CR≥10) | 85/85/85/85 (L/R/U/D) |
| Color Depth | 16.7M Colors, 72% NTSC |
| Weight | 1.66 ± 0.08 kg |
| Refresh Rate Options | 60Hz 120Hz (60Hz Input, with MEMC) 120Hz+120Hz (120Hz Panel + 120Hz Backlight) 240Hz (60Hz Input, with MEMC) |
| Surface Treatment | Anti-glare (Haze 25%), Hard Coating (3H) |
| Contrast Ratio | 3000:1 (Typ., Transmission) |
| Optical Mode | MVA, Normally Black, Transmissive IPS Series Supported: AAS/ADS/AHVA/FFS/HFS/HIS/IPS/New Mode2/PLS/SFT/Vistarich VA Series Supported: ASV/FSA/HVA/MVA/PVA/SVA/UV²A/VA |
| Response Time | 15/5 ms (Tr/Td), 25 ms (Gray-to-Gray) |
| Backlight System | WLED, 50,000 hours, Built-in LED Driver |
| Application | Industrial Use |
| Touch Function | No Touch |
| Signal Interface | LVDS (2-channel, 8-bit), 30-pin connector |
| Power Supply | 5.0V (Typ.) |
| Storage Temperature | –20 ~ 60 °C |
| Operating Temperature | 0 ~ 50 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
