15-inch high brightness industrial LCD panel for a variety of industrial applications. With excellent picture quality and high brightness, it can be clearly displayed under strong light. Reliable and durable, suitable for use in harsh working environments.
RS150X0M-GE10
RS150X0M-GE10 main features
Industrial LCD Panel
1000 nits (cd/m2) sunlight readable Brightness
Long-Life Advanced LED Backlight, over 100,000 Hours Half-Life
Wide Operational Temperature Range -20°C to 70°C
Touch Screen Technologies Available (Optional)
The 15 inch high brightness industrial LCD panel has a resolution of 1024 by 768. The product uses thin film transistor technology, with high definition and vivid image display effect. Its moderate panel size makes it suitable for a variety of display applications, such as televisions, monitors and industrial control systems.
The panel uses LED backlight technology for high brightness and energy efficiency. LED backlights provide uniform brightness and have a long service life. This panel has a high contrast ratio and can present a more realistic and clear image.
The 15-inch TFT-LCD panel also has a wide viewing Angle, meaning that viewers can view the content on the screen from different angles without losing color and image accuracy.
In addition, this panel also has the characteristics of fast response, enabling smooth video playback and gaming experience. It also supports a wide color gamut, allowing for richer and more vibrant colors.
In short, the 15-inch LCD panel has a resolution of 1024*768, high definition, sharp image display effect, LED backlight technology, wide viewing Angle, fast response speed and wide color gamut, which is suitable for a variety of display applications.
| Screen Diagonal | 15 Inch |
| Brand | Risingstar |
| Model No | RS150X0M-GE10 |
| Active Area | 304.128(W)×228.096(H) mm |
| Resolution | 1024(RGB)×768, XGA, 85PPI |
| Physical Size | 326.5(W)×253.5(H)×10(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 1000:1 |
| White Luminance ( Center ) | 1000 nits |
| Optical Response Time | 30 (Typ.)(Tr+Td) ms |
| Nominal Input Voltage | 3.3V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [g] | 930g(Typ.) |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Support Color | 16.7M , 72% NTSC |
| Surface Treatment | Fog level(Haze 25%),Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | -20 ~70 °C |
| Storage (Non-Operating) | -20 ~ 70 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
