RS185HAN-GE10 is industrial LCD display with 1000 nits high brightness, aluminum die casing, strong and easy heat dissipation, suggest to be applied to industrial medial imaging, automatic industrial production monitoring and controlling.
Industrial LCD display has many advantages over commercial or consumer grade display, they can work under more rugged, such as high temperature, low temperature situation.
RisingLCD RS185HAN-GE10 is industrial LCD panel with 1000 nits high brightness, 1920*1080 HD resolution, 89/89/89/89 wide viewing angle, 1000:1 contrast ratio, -20 ~ 70 °C degree working temperature, suggest to be applied to industrial medial imaging, automatic industrial production monitoring and controlling.
RS185HAN-GE10 industrial high brightness LCD Main Features:
AUO original LCD panel
High resolution: 1920*1080
Brightness up to 1000 nits
Auto brightness control
Wide industrial working temperature
Almuinum alloy structure easy heat dissipation
24/7 working time
RisingLCD can offer the high brightness industrial LCD screen from 10.1 inch to 110 inch, and brightness from 700 nits to 5000 nits, high brightness displays provide a vibrant and bright solution for window advertising, traffic information, they are perfect for the outdoor digital signage application in airport, bus/train/raiway/ station and retail shop window.
| Screen Diagonal | 18.5 inch |
| Brand | RisingLCD |
| Model No | RS185HAN-GE10 |
| Active Area | 408.96(W)×230.04(H) mm |
| Resolution | 1920(RGB)×1080, FHD, 119PPI |
| Physical Size | 430.4(W)×254.6(H)×12.5(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 1000:1 |
| White Luminance ( Center ) | 1000 cd/m2 (Typ.) [cd/m2 ] |
| Optical Response Time | 10/10 (Typ.)(Tr/Td) ms |
| Nominal Input Voltage | 5.0V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Power (watt) | 21W |
| Weight [kg] | 1.20kgs |
| Interface Type | 30 pins LVDS (2 ch, 8-bit) |
| Support Color | 16.7M , 99% sRGB |
| Surface Treatment | Matte, Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | -20 ~70 °C |
| Storage (Non-Operating) | -20 ~ 70 °C |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
