P281SVN01.0 is a 28.1 inch hi-tni industrial square tft lcd display from AUO, it is with an integral WLED backlight system, With LED Driver, without touch screen. 800*800 resolution, 1000 nits high brightness, 4000:1 contrast ratio, LVDS interface, it features an operating temperature range of -20 ~ 60°C.
P281SVN01.0 is a 28.1 inch hi-tni industrial square tft lcd display from AUO, it is with an integral WLED backlight system, With LED Driver, without touch screen. 800*800 resolution, 1000 nits high brightness, 4000:1 contrast ratio, LVDS interface, it features an operating temperature range of -20 ~ 60°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.04G (10.2 m/s²). Landscape / Portrait, 1000 nits High Brightness, WLED Backlight, Life ≥ 70K hours, With LED Driver, Bar Display, Matte, Liquid crystal: Advanced wide temperature LC (-40-110°C), hi- tni panel. Based on its features, it is ideal to be applied to Digital Signage, Outdoor High Brightness etc.
28.1 inch Square TFT LCD, 1000 nits LED Backlight , 800*800 resolution
28.1 inch hi-tni tft LCD
High Brightness 1000 nits
LED Backlight
LCD blacking defect free (Hi-Tni 110 ˚C)
Low Power Consumption
Hi-tni Blackening Defect Free
A hi-Tni panel is a type of display panel that is specifically designed to prevent blackening when the display operates under elevated temperature conditions. This is particularly important for displays that are used outdoors, where there are high ambient temperatures and a high bright backlight, which can cause the display to overheat and become damaged.
AUO high tni (110°c) liquid crystal panel
P281SVN01.0 700 Adv. Hi-Tni LC (-40~110℃), Photo mask, 70Khrs 24 MP
P236RVN01.0 700 Adv. Hi-Tni LC (-40~110℃), Photo mask, 70Khrs 24 MP
P430QVT01.0 400 1500R C type LCM with Touch 24 MP
P430QVR01.0 500 1500R C type LCM 24 MP
P215HAN02.0 1500 AHVA, H-Tni LC even bezel, E-LED, 70Khrs 24 MP
P320HVN04.3 1500 Adv. Hi-Tni LC (-40~110℃), D-LED 24 EOL_Y23/Jun
P320HVN04.4 1500 Adv. Hi-Tni LC (-40~110℃), D-LED, (L) 24 2023/Feb
P320HVN04.5 1500 Adv. Hi-Tni LC (-40~110℃), D-LED, (P) 24 2023/Feb
P430HVN05.1 1500 Adv. Hi-Tni LC (-40~110℃), AG28%, (P) 24 MP
P430HVN05.2 1500 Adv. Hi-Tni LC (-40~110℃), AG28%, (L) 24 2023/Jun
P460HVN04.4 1500 Adv. Hi-Tni LC (-40~110℃), AG28%, (P) 24 MP
P460HVN04.5 1500 Adv. Hi-Tni LC (-40~110℃), AG28%, (L) 24 MP
P320HVN07.0 2500 Adv. Hi-Tni LC (-40~110℃), D-LED 24
P320HVN07.1 2500 Adv. Hi-Tni LC (-40~110℃), D-LED, (L) 24 2023/Feb
P320HVN07.2 2500 Adv. Hi-Tni LC (-40~110℃), D-LED, (P) 24 2023/Feb
P430HVN06.1 2500 Adv. Hi-Tni LC (-40~110℃), AG28% (P) 24 2023/Sep
P460HVN05.0 2500 Adv. Hi-Tni LC (-40~110℃), AG28%, 70Khrs 24 MP
P460HVN05.1 2500 Adv. Hi-Tni LC (-40~110℃), C-POL 24 MP
| Screen Diagonal | 28.1 inch |
| Auo panel no | P281SVN01.0 |
| Model No | RS281NET-GE10 |
| Active Area | 504(W)×504(H) mm |
| Pixels | 800(RGB)×800 40PPI |
| Physical Size | 526.8(W)×526.8(H)×28.2(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| White Luminance ( Center ) | 1000 cd/m2 (Typ.) [cd/m2 ] |
| Contrast Ratio | 4000:1 (Typ.) |
| Optical Response Time | 8 (Typ.)(G to G) |
| Nominal Input Voltage | 12V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down |
| Weight [g] | 3.60 kgs |
| Interface Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Support Color | 16.7M/1.07B 72% NTSC |
| Surface Treatment | Antiglare (Haze 2%) |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | -20 ~60 °C |
| Storage (Non-Operating) | -20 ~ 60 °C |
