RisingStar directly supply a complete line of outdoor digital signage LCD display. This product line is designed to operate in any outdoor environment, even in a direct sunlight.
The 55 inch outdoor digital display is engineered for demanding outdoor environments where visibility, reliability, and durability are critical. Designed with a high brightness panel of up to 1000–5000 nits, this display ensures exceptional visibility even under direct sunlight, making it ideal for applications such as transportation hubs, shopping centers, public squares, QSR drive-thrus, and EV charging stations.
Built with an industrial-grade aluminum housing, the display offers full IP65/IP66 protection against water, dust, and harsh weather conditions. The structure is lightweight yet robust, supporting 24/7 operation with a lifespan exceeding 50,000 hours. Advanced direct-lit LED backlighting ensures uniform brightness and high contrast, while a wide operating temperature range allows stable performance from -30°C to 70°C.
This 55-inch unit also supports smart CMS integration, remote diagnostics, and is available with optional features such as touch functionality, anti-reflective glass, and embedded sensors. As an experienced manufacturer of outdoor digital displays, we prioritize long-term reliability, energy efficiency, and seamless integration for any outdoor signage project.
RisingStar 55 inch outdoor digital display Stock Sizes
outdoor digital display | ||||||
| Panel | Panel Size | 32 inch | 43 inch | 49 inch | 55 inch | 65 inch |
| Panel Brand | RisingStar | |||||
| Display Area(mm) | 698.4*392.8 | 941*529.4 | 1074*604 | 1209*680 | 1428*803 | |
| Brightness (nits) | 2000 nits | 4000 nits | 2000 nits | 2000 nits | 2000 nits | |
| Resolution | 1920*1080 | 1920*1080 | 1920*1080/ 3840*2160 | 1920*1080/ 3840*2160 | 1920*1080/ 3840*2160 | |
| Aspect Ratio | 16:9 | |||||
| Contrast Ratio | 1300/1 | |||||
| Response Time | 6/9 (Typ.)(Tr/Td) ms | |||||
| View Angle | 89/89/89/89 (Min.)(CR≥10) | |||||
| Backlight | （DLED) | |||||
| Life Hour | 50000H | |||||
| Control System | Smart Dimming | Support | ||||
| Intelligent Temperature Control | Support | |||||
| Remote Control Function | Support | |||||
| AV Input | Video | HDMI, VGA | ||||
| Electrical Parameters | Input Voltage | AC110V/220V, 50/60HZ | ||||
| Maximum Power | 80W | 280W | 180W | 240W | 300W | |
| Display | Shell Material | Sheet Metal | ||||
| Product Size(mm) | 798*491*108 | 1044*632*123.6 | 1170*700*120 | 1309*780*118.6 | 1524*899*120 | |
| Weight | 30kg | 50kg | 64kg | 67kg | 80kg | |
| Shell Anti-Corrosion Process | Use galvanized sheet + surface spray with special outdoor powder (outdoor anti-corrosion for more than 7 years). | |||||
| Protection Glass | Thickness | 5mm AR tempered glass | ||||
| Accessories | Included | AC Power Cable, Remote Control, Wall Mount | ||||
| Operating Environment | IP Rating | Outdoor IP65 | ||||
| Operating Temperature and Humidity | -20-50℃/5%-95%RH | |||||
| Multimedia | IO Interface | HDMI/VGA/DVI | ||||
| Option | AD Board | Android Motherboard, Computer Motherboard | ||||
| Network Transmission | Standalone Mode、WIFI、3G、4G | |||||
| Touch | 10 points touch, 20 points touch, Capacitive touch | |||||
Outdoor digital display with ultra high brightness RS550ENT-N50 Main features
All-aluminum structure design,
Outstanding visibility high brightness
Smart brightness control
Blackening Defect Free
Conformal Coating
Manage content easily and efficiently
RisingStar use aluminum alloy structure that is high thermal conductivity to maximize heat transfer, reduces the overall operation temperature, it is ideal to use in a higher environment, the heat dissipation is four times that of the ordinary metal structure.
Outstanding visibility high brightness
With a great brightness of 5000nits, this outdoor digital display are well equipped to make the contents and images vividly stand out in any commercial location, you can experience superior pictures quality and optimized visibility.
Smart brightness control
The built-in auto-brightness sensor adjusts backlight brightness according to the surrounding brightness to save power energy and protect your eyes.
Blackening Defect Free
Most residential and commercial screens will blacken or result in isotropic failure when the LCD panel overheats. Our outdoor digital display is equipped with a high-temperature LCD panel capable of withstanding temperatures up to 110˚C (230°F) without blackening – crucial for direct sunlight applications.
Conformal Coating
This outdoor digital display can be often unavoidably exposed to dust and water during maintenance, conformal coating on every major circuit board eliminates such troubles by protecting it against dust, iron powder, humidity, etc.
Plug and play
Plug and play, plug you USB stick that have loaded images and videos into our high brightness window facing display, just only wait for your content copy over, then it can play automically.
outdoor digital display Company Mainly Deals In The Following Sizes, Global OEM/ODM
| Model name | Size(inch) | brightness(nits) | Resolution | Operating temperature | Screen life |
|---|---|---|---|---|---|
| RS101ICE-GE07 | 10.1" | 700-5000 | 1280*800 | -20 ~ 70 ℃ | 15000H |
| RS156HCE-GE10 | 12.1" | 700-5000 | 1920*1080 | -20 ~ 70 ℃ | 70000H |
| RS156HCE-GE10 | 13.3" | 1000-5000 | 1920*1080 | -20 ~ 70 ℃ | 50000H |
| RS156HCE-GE10 | 15" | 1000-5000 | 1920*1080 | -20 ~ 70 ℃ | 50000H |
| RS156HCE-GE10 | 15.6" | 1000-5000 | 1920*1080 | -20 ~ 70 ℃ | 50000H |
| RS190E0M-GE10 | 17" | 1000-5000 | 1280*1024 | -20 ~ 70 ℃ | 30000H |
| RS190E0M-GE10 | 18.5" | 1000-5000 | 1280*1024 | -20 ~ 70 ℃ | 50000H |
| RS190E0M-GE10 | 19" | 1000-5000 | 1280*1024 | -20 ~ 70 ℃ | 30000H |
| RS215FHB-GE15 | 21.5" | 1500-5000 | 1920*1080 | -20 ~ 70 ℃ | 50000H |
| RS215FHB-GE15 | 23.8" | 1500-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 30000H |
| RS270FHB-GD20 | 27" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 40000H |
| RS320DPY-GD30 | 32" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 30000H |
| RS490EPY-GD30 | 43" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 50000H |
| RS490EPY-GD30 | 49" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 30000H |
| RS550DPY-GD45 | 55" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 50000H |
| RS650QUB-GD30 | 65" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 50000H |
| RS750ENT-GD40 | 75" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 50000H |
| RS860EQL-GD40 | 86" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 30000H |
| RS980DQY-GD35 | 98" | 2000-5000 | 1920*1080 / 3840*2160 | -20 ~ 70 ℃ | 50000H |
| More size enquiries... | ai@risinglcd.com |
With over a decade of experience in industrial-grade LCD development, RisingLCD specializes in engineering digital signage displays that perform flawlessly in extreme outdoor environments. Our R&D team continuously innovates to optimize optical bonding, thermal management, and energy efficiency—ensuring unmatched clarity and durability under direct sunlight.
RisingLCD solutions have been deployed in over 30 countries across transportation hubs, EV charging kiosks, marine systems, and outdoor retail signage. Our displays meet rigorous standards including IP65/IP67 waterproofing, wide temperature operation, and compliance with CE, FCC, and RoHS certifications.
Each display undergoes extensive testing—including sunlight simulation, vibration, salt fog, and thermal cycling—to ensure performance in real-world conditions. Our customers consistently report significant visibility improvements and reduced maintenance costs in field deployments.
We believe in transparency and long-term cooperation. Every product comes with detailed specifications, lifecycle support, and a dedicated technical contact. Have a question or need customization? Reach out via our contact page or email us directly at info@risinglcd.com.
A sunlight readable digital signage display typically offers brightness levels above 1000 nits, combined with anti-reflective coatings, wide viewing angles, and sometimes optical bonding to minimize glare. RisingLCD's high brightness LCDs can reach up to 3000 nits, ensuring clear visibility even under direct sunlight.
These displays are widely used in outdoor environments such as EV charging stations, gas pumps, marine navigation, transit information kiosks, and public advertising. RisingLCD's displays are engineered for extreme outdoor performance, ensuring reliability in high humidity, intense light, and temperature variations.
Our displays undergo rigorous testing including thermal cycling (-30°C to +80°C), salt fog corrosion, and IP-rated waterproofing. We also use industrial-grade components, full aluminum housing, and advanced thermal management to guarantee up to 50,000 hours of operating life.
Yes. We offer fully customizable display solutions including screen size, brightness levels, touch functionality, mounting design, and sunlight protection. Our engineering team will work closely with your integration requirements to ensure optimal results.
With over 10 years of expertise in high brightness display manufacturing, RisingLCD is trusted by global integrators for its product quality, engineering support, and after-sales service. All our displays meet CE, FCC, and RoHS standards, and come with long-term lifecycle support.
Simply contact our sales or engineering team via Contact Page or email us at ai@risinglcd.com. We'll respond within 24 hours and help you find the most suitable display for your outdoor application.
| Item | Specification |
|---|---|
| Panel Size | 55 inches |
| Panel Type | a-Si TFT-LCD, Liquid Crystal Module |
| Resolution | 1920 (RGB) × 1080 (FHD), 40 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 1209.6 (W) × 680.4 (H) mm |
| View Area | 1216 (H) × 686.8 (V) mm |
| Brightness | 1000 to 5000 nits |
| Viewing Direction | All View / 89° Left / 89° Right / 89° Up / 89° Down (CR≥10) |
| Color Depth | 1.07 Billion Colors, 73% NTSC |
| Weight | 15.0 Kgs |
| Refresh Rate | 60Hz (Standard), 120Hz (with MEMC), 240Hz (with MEMC, backlight sync) |
| Surface Treatment | Anti-glare (Haze 28%) |
| Contrast Ratio | 4000:1 (Typical, Transmissive) |
| Response Time | 8ms (Typical, G to G) |
| Display Mode | AMVA3, Normally Black, Transmissive |
| Backlight Type | WLED with LED Driver |
| Backlight Lifetime | 60,000 hours |
| Touch Panel | No Touch |
| Interface Type | 51 pins LVDS (2 channel, 10-bit) |
| Input Voltage | 12.0V (Typical) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -20°C to +60°C |
| Recommended Applications | Outdoor Digital Signage, High Brightness Displays, Industrial Display Systems |
