Specifications
Specification Parameter | |||||
LCD Panel | Size | 32 | 49 | 55 | 65 |
Brand | LG/AUO/BOE | ||||
Display Area | 698*4*392*8mm | 1074*604mm | 1209*680mm | 1428*803mm | |
Brightness | 2000nits | ||||
Resolution | 1920*1080 | 1920*1080/3840*2160 | 1920*1080/3840*2160 | 1920*1080/3840*2160 | |
Ratio | 16 / 9 | ||||
Contrast | 1300:1 | ||||
Respond time | 6/9 (Typ.)(Tr/Td) ms | ||||
View angle | 89/89/89/89 (Min.)(CR≥10) | ||||
Led | DLED | ||||
Lifetime | 50000H | ||||
Control System | Intelligent dimming | Support | |||
Intelligent temperature control | Self cooling | ||||
Touch | Capacitive touch (optional) | ||||
Electric Parameter | input voltage | AC90-264V,50/60HZ | |||
Maximum Power | 80W | 180W | 220W | 300W | |
Outer Shell | IP rated | IP66 | |||
shell material | Sheet metal / aluminum alloy | ||||
Size | 798*491*108mm | 1170*700*120mm | 1305*776*120mm | 1524*899*120mm | |
Weight | 30kg | 65kg | 80kg | 108kg | |
Service Environment | operating environment | Full outdoor | |||
Operating temperature and humidity | -20~70℃/5%-95%RH | ||||
Multimedia | Motherboard | Android /PC(optional) | |||
IO Interface | USB/RJ45 | ||||
RS32-OEM is a 32-inch LCD display with 2,000 nits brightness, 1920×1080 resolution and 1300:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
Risingstar outdoor monitor design for 24/7 operation in harsh outdoor weather conditions, construction in lightweight aluminum or rugged steel, tempered glass and low profile controls to protect the display from import shock and vibration damage.
Main features:
Ultra high brightness panel of 2500 nits (sunlight readable)
Advanced smart temperature control system
Toughened glass
Sturdy enclosure & vandal proof
Plug and play
Anti-reflective glass
External ports to attach devices
Dust Tight
Weather proof
Free Lockable wall mount
light sensor
RisingStar LCD outdoor video monitor display are available as wall mount monitor and floor mount kiosk, the standard range of the sizes are 32 inch, 43 inch, 49 inch, 55 inch, 65 inch, 75 inch, all of these models feature wide viewing angles, that make them suitable for portrait and landscape orientation.
Product FAQs
-
It is rated at 2,000 nits (cd/m²) brightness.
-
It uses a 32-inch panel, 1920×1080 resolution, 1300:1 contrast ratio.
-
The operating temperature range is -20 °C to 70 °C.
-
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
-
It adopts USB/RJ45 interface.
-
The power input requirement is AC90-264V,50/60HZ.
-
Yes. Rated at 2,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
-
Its protection rating is IP66, so it is built for outdoor and semi-outdoor installation.
-
Yes. It is fitted with Support, so screen brightness adapts to ambient light.
