32 inch outdoor waterproof high brightness LCD monitor
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
Risingstar outdoor monitor design for 24/7 operation in harsh outdoor weather conditions, construction in lightweight aluminum or rugged steel, tempered glass and low profile controls to protect the display from import shock and vibration damage.
Main features:
Ultra high brightness panel of 2500 nits (sunlight readable)
Advanced smart temperature control system
Toughened glass
Sturdy enclosure & vandal proof
Plug and play
Anti-reflective glass
External ports to attach devices
Dust Tight
Weather proof
Free Lockable wall mount
light sensor
RisingStar LCD outdoor video monitor display are available as wall mount monitor and floor mount kiosk, the standard range of the sizes are 32 inch, 43 inch, 49 inch, 55 inch, 65 inch, 75 inch, all of these models feature wide viewing angles, that make them suitable for portrait and landscape orientation.
Specification Parameter | |||||
LCD Panel | Size | 32 | 49 | 55 | 65 |
Brand | LG/AUO/BOE | ||||
Display Area | 698*4*392*8mm | 1074*604mm | 1209*680mm | 1428*803mm | |
Brightness | 2000nits | ||||
Resolution | 1920*1080 | 1920*1080/3840*2160 | 1920*1080/3840*2160 | 1920*1080/3840*2160 | |
Ratio | 16 / 9 | ||||
Contrast | 1300/1 | ||||
Respond time | 6/9 (Typ.)(Tr/Td) ms | ||||
View angle | 89/89/89/89 (Min.)(CR≥10) | ||||
Led | DLED | ||||
Lifetime | 50000H | ||||
Control System | Intelligent dimming | Support | |||
Intelligent temperature control | Self cooling | ||||
Touch | Capacitive touch (optional) | ||||
Electric Parameter | input voltage | AC90-264V,50/60HZ | |||
Maximum Power | 80W | 180W | 220W | 300W | |
Outer Shell | IP rated | IP66 | |||
shell material | Sheet metal / aluminum alloy | ||||
Size | 798*491*108mm | 1170*700*120mm | 1305*776*120mm | 1524*899*120mm | |
Weight | 30kg | 65kg | 80kg | 108kg | |
Service Environment | operating environment | Full outdoor | |||
Operating temperature and humidity | 0-50℃/5%-95%RH | ||||
Multimedia | Motherboard | Android /PC(optional) | |||
IO Interface | USB/RJ45 | ||||
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
