55 inch 2000 nits retail window LCD display
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
Window displays are not just a visual entry point into a store, they are eye-catching, capture the shopper's imagination and convey not just a brand vision but a way of life.
Ultra-high brightness
The ultra-high brightness of 2,000 cd/㎡ can clearly transmit content and attract the attention of the public. It is the ultimate display for outdoor visibility.
Polarized Sunglasses Visible
Clearly visible even when the viewer is wearing polarized sunglasses.
Fanless Design
Its operating noise level is below 25dB, which is quieter than everyday conversation.
Space Efficient, Ultra-Thin Design
Due to its thinner depth, it takes up less space, resulting in improved space efficiency in an in-window environment.
| Specification Parameter | |
| Size | 55 |
| Panel Brand | LG/AUO/BOE |
| Display Area | 1209*680mm |
| Brightness | 2000nits |
| Resolution | 3840*2160 |
| Aspect Ratio | 16:09 |
| Contrast | 1300/1 |
| Response Time | 6/9 (Typ.)(Tr/Td) ms |
| View Angle | 89/89/89/89 (Min.)(CR≥10) |
| LED | DLED |
| Lifetime | 50000H |
| Intelligent dimming | Support |
| Intelligent temperature control | Support |
| Remote Control | Support |
| Input Voltage | AC90-264V,50/60HZ |
| Maximum Power | 265W |
| Shell Material | Metal Plate |
| Product Dimensions | 1254.5*725.4*89mm |
| Weight | 34KG |
| environmental conditions | Semi-outdoor |
| Operating temperature & humidity | -20 ~ 70 °C |
| Main-board | Android /PC/ HD Driver Board (Optional) |
| IO interface | HDMI/VGA/DVI/USB/RJ45 |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
