Specifications
| Parameter | Value |
|---|---|
| Model Name | RS490MNX03D01 |
| Screen Size | 49" |
| Display Area (mm) | 1073.78(W)×604(H) mm |
| Brightness | 3000 cd/m2 |
| Resolution | 1920x1080 |
| Aspect Ratio | 16 : 9 |
| Contrast Ratio | 1300 : 1 |
| Response Time (Typical) | 8(Typ.)(Tr/Td) (ms) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Display Colors | 16.7M/1.07B, 96% sRGB |
| Motherboard | Android/PC/Monitor(optional) |
| Tempered Glass | N/A |
| Touch Type | N/A |
| Input Power | AC100-240V |
| Power Consumption | 318W |
| Radiator System | The fan will automatically start to cool down when the temperature exceeds 35℃ |
| Input Interface | HDMI/VGA/DVI/USB/RJ45(optional) |
| Dimensions (mm) | 1098.8*629*50mm |
| Shell | Metal sheet/Aluminnum Alloy |
| Mounting | 400x400mm 4-M8,MAX_DEPTH=10mm |
| Weight (Net) | 22kg |
| IP（Ingress Protection） | N/A |
| Operating Temperature | 0℃~50℃ |
| Storage Temperature | -20℃~ 60℃ |
Product Overview
The 49-inch Window Facing LCD Display RS490MNX03D01 from RisingStar expands our window-facing display lineup. It features an active area of 1073.78 × 604 mm and 3000 cd/m² brightness, enabling a single screen to fill the glazing of double-front storefronts while maintaining clear visuals under daylight.
Colour reproduction is a core strength of this model. It delivers 1.07 billion colours, 96% sRGB coverage and a 1300:1 contrast ratio, ensuring colours of fabrics, cosmetics and product packaging stay true to real‑world samples — critical when customers view merchandise through shop glass. The display supports both landscape and portrait orientation, with automatic ambient light brightness adjustment. It shares the same 50 mm slim profile and 400 × 400 mm VESA mounting specification as other models in the series.
Key Features
- 3000 nits ultra-high brightness
- Ultra high contrast ratio: 1300:1
- Sunlight viewable performance
- Zero blacking defect LCD panel
- Landscape & portrait orientation support
- Auto-brightness control
- Low power consumption
- Backlight MTBF: 100,000 hours
Typical Applications
- Fashion and luxury brand store windows
- Cosmetics and jewellery retail displays
- Consumer electronics shopfront windows
- Supermarket promotional window signage
- Hotel and lobby glass facade installations
