    17 inch 700 nits high brightness TFT LCD panel
    • 17 inch 700 nits high brightness TFT LCD panel
    • 17 inch 700 nits high brightness TFT LCD panel
    • 17 inch 700 nits high brightness TFT LCD panel

    17 inch 700 nits high brightness TFT LCD panel

    Brand:

    LG/AUO/BOE

    Model name:

    RS170ETN-NE07

    Screen size:

    17"

    Screen type:

    Outdoor LCD Panel

    Resolution:

    1280(RGB)×1024

    Brightness (cd/m²):

    700



    *Name:
    *Country:
    *E-mail:
    Phone:
    *Content:

    Product Introduction: 17 inch 700 nits TFT LCD Panel

    Our 17 inch 700 nits TFT LCD panel is a cutting-edge display solution that offers superior brightness, visual clarity, and enhanced viewing experience. This high-performance panel is designed to meet the demanding requirements of a wide range of applications, including outdoor digital signage, industrial displays, medical systems, and transportation displays.

    With a luminance of 700 nits, this TFT LCD panel ensures excellent visibility even under direct sunlight or brightly lit environments. The high brightness feature enables crisp and vibrant image reproduction, making it an ideal choice for outdoor digital signage applications. The panel's enhanced visibility is further enhanced by its wide viewing angles, allowing viewers to see the content clearly from various perspectives.

    In addition to its impressive brightness, the 17-inch TFT LCD panel boasts a resolution of (insert specific resolution), ensuring sharp and detailed image quality. The panel's fast response time ensures smooth video playback.

    With its versatile features and sturdy design, the 17 inch 700 nits TFT LCD panel provides a reliable and high-quality display solution. Its excellent visibility, sharp image quality, and durability make it the perfect choice for a wide range of applications where brightness and durability are paramount.

    If you need more information, please contact us and we will reply you as soon as possible

    17 inch 700 nits TFT LCD panel


    Hot Tags: 17 inch 700 nits high brightness TFT LCD panel, manufacturers, suppliers, factory, Customized
    Screen Diagonal17 inch
    Model NoRS170ETN-NE07
    Active Area 337.92(W)×270.336(H) mm
    Pixels1280(RGB)×1024,
    Physical Size358.5(W)×296.5(H)×10.8(D) mm
    Pixel Arrangement R.G.B. Vertical Stripe
    Display Mode a-Si TFT-LCD, LCM
    White Luminance ( Center )700 cd/m2 (Typ.)  [cd/m2 ]
    Contrast Ratio 1000:1 (Typ.)
    Optical Response Time 8 (Typ.)(G to G) ms
    Nominal Input Voltage 12V (Typ.)
    Frame Rate60Hz
    Viewing Angle85/85/80/80 (Typ.)(CR≥10)
    Weight 1.27Kgs (Typ.)
    Interface Type LVDS (2 ch, 8-bit)  , 30 pins Connector
    Support Color 16.7M (6-bit + Hi-FRC)
    RoHS Compliance RoHS Compliance
    Temperature Range0 ~50 °C
    Storage (Non-Operating) -20 ~ 60 °C
