Specifications

Items

Specification

Note

Panel Brand

LG


Diagonal Size

43" 50" 55" 65" 75"


Panel Type

a-Si TFT-LCD

LCM

Resolution

1920(RGB)×1080 91PPI


Pixel Format

RGB Vertical Stripe


Display Area

1095.84 × 616.41 mm (H×V)


Outline Size

1215.04×738.41×95 mm (H×V×D)


Surface

Antiglare (Haze 1%), Hard coating (2H).


Brightness2000 nits standard, up to 3000 nits optional

Contrast Ratio

1400:1 (Typ.) (TM)


waterproof level

IP65 IP66 IP66


Protection level

IK10


Support Color

1.67B 100% NTSC


Viewing Angle

89/89/89/89 (Min.)(CR≥10)


Display Mode

IPS, Normally Black, Transmissive .


Response Time

5 (Typ.)(G to G); 8 (Typ.)(MPRT).


Lamp Type

WLED, 50K hours, With LED Driver


Frequency

60Hz


Panel Weight

45.0/47.0Kgs (Typ./Max.)


Application

Restaurant Menu LCD Panel


Signal Interface

HDMI/ DP / DVI / RJ45 / RS232 / USB


Input Voltage

110 to 260V (Typ.).


Operating Temperature

-20~70 °C

Storage Temperature

-30~80 °C

RS500ENT-N20 is an LCD display with 2,000 nits brightness, 1920×1080 resolution and 1400:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

The Risingstar Restaurant  Menu LCD Panel modernizes your menu. Turn your static food and drink list into a dynamic visual experience, which is mouth-watering. The Restaurant  Menu LCD Panel can display a mix of video clips, animations and images to attract your customers and attract traffic into your restaurant. By using an effective menu design, your eyes will soon become bigger than your stomach.

At Risingstar, we can provide you with a large number of Restaurant  Menu LCD Panel solutions. Successful cases: McDonald's, KFC, Starbucks, etc.

Functions and features:

1. LG original LCD panel, industrial-grade LCD panel is better than ordinary LCD panel

2. High resolution 1920*1080/3840*1080, can be customized

3. How high the working temperature is -0-60 degrees Celsius

4. Brightness up to 2000 nits

5. 50,000 hours long life

6. Support text, picture, video

7. Support horizontal/vertical screen playback

8. Interface: HDMI(2)/DP/DVI-D/RJ45/RS232C/USB

9. Android/windows/raspberry pi/display board

#81

Product FAQs

How bright is the RS500ENT-N20?

It is rated at 2,000 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 1920×1080 resolution, 1400:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the RS500ENT-N20 use?

It adopts HDMI/ DP / DVI / RJ45 / RS232 / USB interface.

What is the power input requirement for the RS500ENT-N20?

The power input requirement is 110 to 260V (Typ.)..

What is the viewing angle?

The viewing angle is 89/89/89/89 (Min.)(CR≥10).

Is the RS500ENT-N20 suitable for outdoor or high-ambient-light use?

Yes. Rated at 2,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Antiglare (Haze 1%), Hard coating (2H)..

What panel technology does the RS500ENT-N20 use?

It uses a-Si TFT-LCD.
