Specifications
Size | 10.1inch | |||
Panel item | RS101NET-N07 | |||
Panel type | a-Si TFT-LCD | |||
Display mode | IPS,Normally black，transmissive display | |||
Pixels | 1280*800 | |||
| brightness | 1300cd/m2 | |||
Contrast Ratio | 800:1 | |||
Response Time | 14/11ms | |||
Viewing Angle | 85/85/85/85 | |||
View area | 218.96*137.6mm(H*V) | |||
Display Area | 218.96*137.6mm(H*V) | |||
Outline Size | 230.7*152.55*7mm(H*V*D) | |||
Signal Type | LVDS | |||
Refresh Rate | 60Hz | |||
Operating Temperature | -20~70°C | |||
Storage Temperature | -30~80 °C | |||
Aspect Ratio | 16:9 | |||
Display color | 16.7m | |||
Backlight Voltage | 3.3V | |||
Backlight Power Consumption | 6.18w | |||
Surface Treatment | Haze | |||
Weight | 0.375kgs | |||
RS101ENT-N13 is a 10.1-inch LCD display with 1,300 nits brightness, 1280×800 resolution and 800:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
Risingstar Good Quality TFT LCD Backlight 10.1 inch High Brightness 1300nits LCD Display screen. Resolution 1280*800LVDS,IPS, 1300nits Brightness can be customized. As one high resolution screen enterprises in China, we warmly welcome you to wholesale bulk cheap 10.1" 1300nits, high resolution screen made in China here and get quotation from our factory. All customized products are with high quality and competitive price.
Product FAQs
How bright is the RS101ENT-N13?
It is rated at 1,300 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 10.1-inch panel, 1280×800 resolution, 800:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS101ENT-N13 use?
It adopts LVDS interface.
What is the power input requirement for the RS101ENT-N13?
The power input requirement is 3.3V.
What is the viewing angle?
The viewing angle is 85/85/85/85.
Is the RS101ENT-N13 suitable for outdoor or high-ambient-light use?
Yes. Rated at 1,300 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Haze.
What panel technology does the RS101ENT-N13 use?
It uses a-Si TFT-LCD.
