Specifications
| 24.0" AUO G240UAN01.0 TFT LCD Panel Module | |
| Brand | AUO |
| Model | G240UAN01.0 |
| Diagonal Size | 24.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 94PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 518.4(H)×324(V) mm |
| Outline Dim. | 546.4(H)×352(V) ×18.6(D) mm |
| Bezel Area | 521.4(H)×327.0(V) mm |
| Treatment | Antiglare |
| Luminance | 900 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 1.07B 78% NTSC |
| Light Source | WLED , 50K hours, With LED Driver |
| Weight | 2.50Kgs (Typ.) |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 10-bit), 51 pins Connector |
| Power Supply | 12.0±1.2V |
| Environment | Operating Temp: -20~70 °C ; Storage Temp: -30~80 °C |
| Current State: | In Production |
RS24ENT-N09 is a 24-inch LCD display with 900 nits brightness, 1920×1200 resolution and 1000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
RisingStar 24 inch 1920*1200 IPS AUO display G240UAN01.0 lcd panel with 1000 nits sunlight readable
ShenZhen RisingStar (RisingStar) 24" high brightness LCD screen, the high brightness 900cd/m2, High resolution 1920*1200, Full view angle,
High constrast 1000:1.
This LCD display is highly desired feature in a situation of strong sunlight conditions, it could be fully readable in the sunlight.
Displays with high brightness many be successfully used e.g in expositions, stands, trains and buses, digital signage or other outdoor applications.
Hot Tags: M240UW01 V0 24 inch a-si tft lcd module, China, factory, cheap, price, customized, quotation, window facing LCD, Outdoor suspended advertising player, Smart LCD advertising player, Transparent LCD panel, LCD Splicing display
M240UW01 V0, M240UW01 V1, M240UW02 V2, G240UAN01.0, G240UAN01.1
Product FAQs
How bright is the RS24ENT-N09?
It is rated at 900 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 24-inch panel, 1920×1200 resolution, 1000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS24ENT-N09 use?
It adopts LVDS (2 ch, 10-bit), 51 pins Connector interface.
What is the power input requirement for the RS24ENT-N09?
The power input requirement is 12.0±1.2V.
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10).
How is the screen surface treated?
The panel surface treatment is Antiglare.
