P650HVN05.1 is a 65-inch advertising outside big screen that with 1920(RGB)*1080 resolution, and this screen is equipmented with a direct-light source LED backlight. P650HVN05.1 adopts LVDS (2 ch, 10-bit) signal interface, 51 pins, which are connected by terminals, and the drive voltage is 12.0V (Typ.)
AUO 65" advertising outside big screen P650HVN05.1 General Description:
P650HVN05.1 is a 65-inch advertising outside big screen that with 1920(RGB)*1080 resolution, and this screen is equipmented with a direct-light source LED backlight. P650HVN05.1 adopts LVDS (2 ch, 10-bit) signal interface, 51 pins, which are connected by terminals, and the drive voltage is 12.0V (Typ.)
This screen characterizes wtih a brightness of 2500 cd/m², a static contrast ratio of 4000:1 and an ability to work in the industrial temperature range (0~50°C).
High brightness and contrast ratio are the main features of this screen, it can work for a long time with wide range of temperatures, and could be read from any angle, no gray scale inversion effect due to the IPS/MVA technology. it is recommended successfully to be applied as a wall mount advertising display( Standalone/network/touch screen), wall-mounted, vertical, horizontal, embedded, desktop, a variety of installation ways.
With original AUO P650HVN05.1 screen, We, RisingLCD China factory can customize it as your wanted!
OEM and ODM are welcomed!
RisingLCD Advantage:
OEM/ODM is acceptale!
Small MOQ is acceptable!
Competitive price!
Fast Delivery time!
RisingLCD is your best choice!
Ref no. P650QVN06.0, P650QVN05.0
Hot Tags: sunlight screen 2500 nits lcd panel, China, factory, cheap, price, customized, quotation, window facing LCD, 3000 cd/m² LCD Display, 43 Charging Pile LCD Advertising Player, 55 Inches Highlight LCD, 1000 cd/m²s LCD Screen, 82 LCD E-Reader, 21.5 LCD Strip Screen
| AUO 65" advertising outside big screen P650HVN05.1 | |
| Panel Brand | AUO |
| Panel Item | P650HVN05.1 |
| Size | 65 inch |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution: | 1920(RGB)*1080(FHD) 34PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1428.48*803.52(H*V)mm |
| Outline Size | 1450.38*825.42*80(H*V*D)mm |
| Bezel Area | 1430.78*805.85(H*V)mm |
| Surface Treatment | Hard coating(2H), Refection 2.0%(Max.) |
| Brightness | 2500cd/m² |
| Constrast Ratio. | 4000:1 |
| View Angle | 89/89/89/89(Min) |
| Display Model | AMVA3, Normally Black, transmissive Display |
| Best View on | Symmetry |
| Response Time | 8 (Typ.)(G to G) ms |
| Display Color | 1.07B 100% Srgb |
| Backlight | WLED, 60K hours, With LED Driver |
| Touch Screen | Without |
| Panel Weight | 20.0Kgs |
| Frame Rate | 60Hz |
| Signal Interface | LVDS (2ch, 10-bit), 51 pins connector |
| Input Voltage | 12v(Typ.) |
| Working Temperature | 0-+50 ﾟC |
| Storage Temperature | -20-+60 ﾟC |
| Current State: | In Production |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
