    AUO 43 inch hi-tni high brightness UHD LCD P430KVN01.0
    • AUO 43 inch hi-tni high brightness UHD LCD P430KVN01.0
    • AUO 43 inch hi-tni high brightness UHD LCD P430KVN01.0

    AUO 43 inch hi-tni high brightness UHD LCD P430KVN01.0

    P430KVN01.0 AUO 43 inch hi-tni tft lcd stretched display 3840*720 resolution, 4000:1 contrast ratio, V-by-One 8 lane , 51 pins Connector interface, 89/89/89/89 viewing angle, 2000 nits high brightness, it is with an integral WLED backlight system, With LED Driver, without touch screen


    Brand:

    Risingstar

    Model name:

    RS430ENT-GE20

    Screen size:

    43"

    Screen type:

    Stretched LCD

    Resolution:

    3840(RGB)×720

    Brightness (cd/m²):

    2000



    *Name:
    *Country:
    *E-mail:
    Phone:
    *Content:

    P430KVN01.0 AUO 43 inch hi-tni tft lcd stretched display 3840*720 resolution, 4000:1 contrast ratio, V-by-One 8 lane , 51 pins Connector interface, 89/89/89/89 viewing angle, 2000 nits high brightness, it is with an integral WLED backlight system, With LED Driver, without touch screen.



    The operating temperature range of -20 ~ 60°C , a storage temperature range of -20 ~ 60°C , Landscape / Portrait, WLED Backlight, Life ≥ 70K hours. The stretched Bar display is with advanced wide temperature LC  (-40-110°C), it features the wide temperature, hi- tni panel. Based on its features, it is ideal to be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc.


    Main features

    1.Hi-tni Blackening Defect Free

    A hi-Tni panel is a type of display panel that is specifically designed to prevent blackening when the display operates under elevated temperature conditions. This is particularly important for displays that are used outdoors, where there are high ambient temperatures and a high bright backlight, which can cause the display to overheat and become damaged.

    Most residential and commercial LCD panel exposed to directly sunlight will blacken or result in isotropic failure. RisingLCD 43 inch hi-tni high brightness LCD IS equipped with AUO high-temperature LCD panel capable of withstanding temperatures up to 110˚C (230°F) without blackening – crucial for direct sunlight applications.



    2.Full viewing angles,

    Thanks to using a matrix with IPS/MVA technology, our high brightness display is readable from any angle. There is no gray scale inversion effect which is a normal feature of popular TN matrixes. A decrease in contrast when increasing the viewing angle is also significantly lower. Superior image quality and color depth at 178 degree ultra-wide portrait orientations. It does not produce image distortion and minimizes color shift when viewed from different angles, it provides clear images and instantly optimizes screen color and brightness.



    3. Outstanding visibility high brightness

    With a great brightness of 2000nits, this hi-tni LCD are well equipped to make the contents and images vividly stand out in any commercial location, you can experience superior pictures quality and optimized visibility



    4K Ultra HD

    The 4K Ultra HD picture quality ensures great colour and rich details in all possible broadcasting surroundings, ranging from retail stores, to restaurants and office buildings.

    With 2000 nits maximum brightness, this digital signage display captive viewers with superior messaging clarity it make your content vividly stand out in any commercial location.


    Hot Tags: AUO 43 inch hi-tni high brightness UHD LCD P430KVN01.0, manufacturers, suppliers, factory, Customized
    Screen Diagonal43 inch
    Auo panel noP430KVN01.0
    Model NoRS430ENT-GE20
    Active Area 1073.78(W)×201.33(H) mm
    Pixels3840(RGB)×720  90PPI
    Physical Size1096.58(H)×224.13(V) ×30(D) mm
    Pixel Arrangement R.G.B. Vertical Stripe
    Display Mode a-Si TFT-LCD, LCM
    White Luminance ( Center )2000 cd/m2 (Typ.)  [cd/m2 ]
    Contrast Ratio4000:1 (Typ.)
    Optical Response Time8 (Typ.)(G to G)
    Nominal Input Voltage 12V (Typ.)
    Frame Rate60Hz
    Viewing Angle89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
    Weight [g] 3.3Kgs
    Interface TypeV-by-One 8 lane , 51 pins Connector
    Support Color 1.07B   72% NTSC
    Surface Treatment Antiglare (Haze 28%), Hard coating (3H)
    RoHS Compliance RoHS Compliance
    Temperature Range -20 ~60 °C
    Storage (Non-Operating) -20 ~ 60 °C
