Specifications
| Screen Diagonal | 42 inch |
| RisingStar panel no | P420IVN01.0 |
| Model No | RS420ENT-GE10 |
| Active Area | 1039.68(W)×259.92(H) mm |
| Pixels | 1920(RGB)×480, 46PPI |
| Physical Size | 1059.48(W)×283.52(H)×56.9(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| White Luminance ( Center ) | 1000 cd/m2 (Typ.) [cd/m2 ] |
| Contrast Ratio | 4000:1 |
| Optical Response Time | 8 (Typ.)(G to G) |
| Nominal Input Voltage | 12V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down |
| Weight [g] | 5.5Kgs |
| Interface Type | LVDS (2 ch, 8/10-bit), 51 pins Connector |
| Support Color | 16.7M/1.07B, 99% sRGB |
| Surface Treatment | Antiglare (Haze 44%), Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS420ENT-GE10 is a 42-inch LCD display with 1,000 nits brightness and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
P420IVN01.0 42 inch hi-tni tft lcd stretched display 1920*480 resolution, 4000:1 contrast ratio, LVDs interface, 89/89/89/89 viewing angle, 1000 nits high brightness, it is with an integral WLED backlight system, With LED Driver, without touch screen.
The operating temperature range of -20~70°C , a storage temperature range of -30 ~ 80°C , Landscape / Portrait, WLED Backlight, Life ≥ 70K hours. The stretched Bar display is with advanced wide temperature LC (-40-110°C), it features the wide temperature, hi- tni panel. Based on its features, it is ideal to be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc.
RisingStar Hi-Tni high brightness LCD Panel list:
P281SVN01.0 700 Adv. Hi-Tni LC (-40~11-20°C), Photo mask, 70Khrs 24 MP
P236RVN01.0 700 Adv. Hi-Tni LC (-40~11-20°C), Photo mask, 70Khrs 24 MP
P430QVT01.0 400 1500R C type LCM with Touch 24 MP
P430QVR01.0 500 1500R C type LCM 24 MP P215HAN02.0 1500 AHVA, H-Tni LC even bezel, E-LED, 70Khrs 24 MP
P320HVN04.3 1500 Adv. Hi-Tni LC (-40~11-20°C), D-LED 24 EOL_Y23/Jun
P320HVN04.4 1500 Adv. Hi-Tni LC (-40~11-20°C), D-LED, (L) 24 2023/Feb
P320HVN04.5 1500 Adv. Hi-Tni LC (-40~11-20°C), D-LED, (P) 24 2023/Feb
P430HVN05.1 1500 Adv. Hi-Tni LC (-40~11-20°C), AG28%, (P) 24 MP
P430HVN05.2 1500 Adv. Hi-Tni LC (-40~11-20°C), AG28%, (L) 24 2023/Jun
P460HVN04.4 1500 Adv. Hi-Tni LC (-40~11-20°C), AG28%, (P) 24 MP
P460HVN04.5 1500 Adv. Hi-Tni LC (-40~11-20°C), AG28%, (L) 24 MP
P320HVN07.0 2500 Adv. Hi-Tni LC (-40~11-20°C), D-LED 24 P320HVN07.1 2500 Adv. Hi-Tni LC (-40~11-20°C), D-LED, (L) 24 2023/Feb
P320HVN07.2 2500 Adv. Hi-Tni LC (-40~11-20°C), D-LED, (P) 24 2023/Feb
P430HVN06.1 2500 Adv. Hi-Tni LC (-40~11-20°C), AG28% (P) 24 2023/Sep
P460HVN05.0 2500 Adv. Hi-Tni LC (-40~11-20°C), AG28%, 70Khrs 24 MP
P460HVN05.1 2500 Adv. Hi-Tni LC (-40~11-20°C), C-POL 24 MP
P460HVN05.2 2500 Adv. Hi-Tni LC (-40~11-20°C), D-LED, (L) 24 2023/Apr
P550HVN06.4 2500 H-Tni, C-POL, black bezel 24 EOL_Sep/23
P550HVN06.6 2500 H-Tni, AG28%, 24 MP
P550HVN06.8 2500 Adv. Hi-Tni LC (-40~11-20°C), C-POL 24 2023/Jun
Product FAQs
How bright is the RS420ENT-GE10?
It is rated at 1,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 42-inch panel, 4000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS420ENT-GE10 use?
It adopts LVDS (2 ch, 8/10-bit), 51 pins Connector interface.
What is the power input requirement for the RS420ENT-GE10?
The power input requirement is 12V (Typ.).
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down.
Is the RS420ENT-GE10 suitable for outdoor or high-ambient-light use?
Yes. Rated at 1,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Antiglare (Haze 44%), Hard coating (3H).
What panel technology does the RS420ENT-GE10 use?
It uses a-Si TFT-LCD, LCM.
