RisingStar 15.6inch Open frame display with Touch screen

RisingStar 15.6inch Open frame display with Touch screen

RisingStar® 15.6 inch RS156ENT-N10-OP sunlight readable display. 1000 nits high brightness, 1920 1080 resolution, Hi-Tni solar-resilient for 24/7 outdoor use.

OEM / ODM Manufacturer

Factory Direct

Order & Lead Time

Sample Order 1 Unit MOQ
Bulk Order 10+ Units Tiered Discounts

Need 50+ units? for framework agreements.

Global Shipping Options

Samples ship in ~10 working days; Bulk orders in 15-25 working days.

  • Express: DHL/FedEx door-to-door delivery (5-7 days)
  • Sea Freight: Cost-optimized bulk shipping (30-45 days)
  • Rush Orders: Available upon request for urgent projects

1-3 Year Standard Warranty

3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.

All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified

Get Started

The RS156ENT-N10-OP is an open-frame touch screen monitor from RisingStar, featuring an original LCD panel from AU Optronics. This display is capable of operating in a wide temperature range, from -20℃ to 60℃, and offers easy connectivity. Due to these features, it is widely used in industrial settings, particularly in manufacturing.

Panel BrandRisingStar
Panel ItemRS156ENT-N10-OP
Size15.6 inch
Panel Typea-Si TFT-LCD, LCM
Resolution:1920(RGB)*1080 70PPI
Pixel FormatRGB Vertical  Stripe
Display Area344.232 × 193.59 mm
Outline Size363.8 × 215.98 mm
Surface TreatmentAG (Haze 28%)  Hard coating(3H)
Brightness1000 cd/m²
Constrast  Ratio.800：1(Typ.)(TM)
View Angle89/89/89/89(Min)
Best View  onSymmetry
Response Time25 ms
Display Color16.7M 72% NTSC
BacklightWLED, 50K hours
Touch ScreenPCAP
Panel WeightTBD
Frame Rate60Hz
Signal InterfaceLVDS(2ch,8-bit), 51 pins connector
Input Voltage3.3V(Typ.)
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
Current State:In Production
RS156ENT-N10-OP 15.6 inch high brightness display 15.6 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display

01 / Chassis & Materials

Structural integrity for extreme environments.

Enclosure Grade Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.
Protection Rating Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.
Surface Finish Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.
Format Architecture Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.

03 / Interface & I/O

Industrial signal and power regulation.

Connectors Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.
Power Regulation Wide voltage DC 9V - 36V input with integrated surge and polarity protection.
Sensor Suite Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.

02 / Optical & Display

Visibility optimization for extreme ambient lighting.

Luminance Output Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology.
Optical Bonding Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio.
Advanced Coating Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.

04 / Embedded & Data

Software architecture and data sync.

Operating Systems Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.
Communication High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.
