49.5 inch high brightness stretch LCD display for passenger information display
21.5 inch open frame TFT LCD monitor with 2500 nits high brightness
High brightness open frame LCD panels
Panel brand: RisingLCD Panel model RS170ENT-N10 Compatible model 1 Compatible model
25 inch LG sunlight readable digital signage Display with 1000 nits brightness
RS430HNX02D05 is a 43 inch outdoor digital signage from Risingstar, it actually the "plus version" of the classic 43-inch window facing display RS430MNX01D01, keep high brightness but lower power consumption.
Risingstar monitors always has far higher brigthness than most of our competitors, for the specific 43-inches we can reached 4000 nits even much higher, more information please searching on our website:
Size (inch) | 21.5 | 32 | 43 | 49 | 55 |
Model number | RS215MNX01D01 | RS320HNX02D05 | RS430HNX02D05 | RS490MNX01D01 | RS550MNX01D01 |
Brightness (cd/m2) | 1000 | 3000 | 2000 | 2000 | 3000 |
Resolution (pixels) | 1920*1080 | 1920*1080 | 1920*1080 | 1920*1080 /3840*2160 | 1920*1080 /3840*2160 |
Power (Watt) | 80 | 160 | 180 | 240 | |
Opreating temperature | 0 ~ 50℃ | -20 ~ 50 ℃ | -20 ~ 50 ℃ | 0 ~ 50℃ | 0 ~ 50℃ |
Top grade LCD panel: Risingstar has ability making our own design LCD panel, and we purchase A and A+ level Open-cell from LG, BOE, AUO and other famous liquid crystal glasses maker directly, this is the proof to make the high qualtiy displays for each of our customers.
Rugged and unique hosuing: This display has unqiue outershell, you can see the crave on the display is as sort of thermal dissipition design by our own design, this allowed the display dissiption heat without fan or A/C, to save the power consumption; it can be fully muted if you need mount it in some quiet place such like library, this also the reason why this outdoor display sometimes will mounted indoor by our customers.
High adaptability electronic: Risingstar has customers from all over the world, EU, US, Asia...using the right plug and adapt different voltage is the basic issue we should figure out for our customers, you do not need worry about this; the possibly OS for the display, we can offer both PC and Android to make you using easier; also the interfaces, HDMI/USB/VGA/DVI/DP/Type-C/RJ45 by your choice, our enegineer will help you found the most suitable motherboard.
Ultra wide viewing angle: Most of the Risingstar display is IPS screen, which has extremely high viewing angle could reach 178° for both horizontal and vertical direction.
Multiple mounting type: for each display our engineer will reserved the mounting hole by your request, you can mouting it on the wall, ceiling, floor standing, hanging...whatever your choice, and our default mouting is VESA.
43-inch window facing display series:
RS430LNX01P01, lower brightness but full waterproof indoor display, special product for low light environment such like Museum/Aquarium...
RS430MNX03D01, semi-outdoor and super slim design, the most highest integrated display we ever made...
RS430MNX01D01, classic design, the standard type of 43-inch window facing display
| Display | Panel Size | 43 inch |
| Panel Brand | LG/AUO/BOE | |
| Display Area | 941*529.4MM | |
| Brightness | 1000 nits / 2000 nits / 3000 nits | |
| Resolution: | 1920*1080 | |
| Aspect Ratio: | 16:9 | |
| Constrast Ratio. | 1300/1 | |
| Response Time | 6/9 (Typ.)(Tr/Td) ms | |
| View Angle | 89/89/89/89 (Min.)(CR≥10) | |
| Backlight | （DLED) | |
| Life Hour | 50000H | |
| Control System | Smart Dimming | Support |
| Intelligent Temperature Control | Support | |
| Remote Control Function | Support | |
| AV Inputs | Video | HDMI, VGA |
| Electrical Parameters | Input Voltage | AC110V/220V,50/60HZ |
| Maximum Power | 160W | |
| Shell | Shell Material | Sheet Metal |
| Product Size | 1044*632*123.6mm | |
| Weight | 50kg | |
| Shell Anti-Corrosion Process | Use galvanized sheet + surface spray with special outdoor powder (outdoor anti-corrosion for more than 7 years). | |
| Protection Glass | Thickness | 5mm AR tempered glass |
| Accessories | Included | AC Power Cable, Remote Control, Wall Mount |
| Operating Environment | Operating Environment | Outdoor IP65 |
| Operating Ttemperature and Humidity | -20-50℃/5%-95%RH | |
| Multimedia | Motherboard Type | Android/PC/HD Driver Board (optional) |
| IO interface | HDMI/VGA/DVI | |
| Option | AD Board | Andorid Mother Board, Computer Mother Board |
| Network Transmission | Standalone Mode、WIFI、3G、4G | |
| Touch | 10 points touch, 20 points touch, Capacitive touch |
Ask a quote for the latest price and one of our team members will respond as soon as possible.
