Specifications

Screen Diagonal43  inch
Brand RisingStar
Model NoRS430IVN-GD30
Active Area1073.78(W)×201.335(H) mm
Pixels1920(RGB)×360, 45PPI
Physical Size1107.4(H)*239.9(V)*54.1(D)
Pixel ArrangementR.G.B. Vertical Stripe
Display Modea-Si TFT-LCD, LCM
Contrast Ratio4000:1
White Luminance ( Center )3000nits
Optical Response Time16 (Typ.)(Tr+Td) ms
Nominal Input Voltage12V (Typ.)
Frame Rate60Hz
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Weight [g]5.2 kgs
Interface Type51 pins   LVDS (2 ch, 8-bit)
Support Color16.7M, 60% NTSC
Surface TreatmentHard coating (3H),
Power consumption138W
RoHS ComplianceRoHS Compliance
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C

RS430IVN-GD30 is a 43-inch LCD display with 3,000 nits brightness and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

43-inch-stretch-bar-display

RisingStar RS430IVN-GD30 – Specification Table

ItemSpecification
Screen Diagonal43 inch
BrandRisingStar
Model No.RS430IVN-GD30
Active Area (mm)1073.78 (W) × 201.335 (H)
Pixels1920 (RGB) × 360, 45 PPI
Physical Size (mm)1107.4 (W) × 239.9 (H) × 54.1 (D)
Pixel ArrangementRGB Vertical Stripe
Display Modea-Si TFT-LCD, LCM
Contrast Ratio4000:1
White Luminance (Center)500 ~ 3000 nits
Optical Response Time16 ms (Typ., Tr+Td)
Nominal Input Voltage12V (Typ.)
Frame Rate60Hz
Viewing Angle (CR≥10)89/89/89/89
Weight5.2 kg
Interface Type51-pin LVDS (2-ch, 8-bit)
Supported Colors16.7M, 60% NTSC
Surface TreatmentHard coating (3H)
Power Consumption138W
RoHS ComplianceYes
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C

Description

The RisingStar RS430IVN-GD30 is a 43-inch industrial-grade stretched LCD panel designed for demanding outdoor and semi-outdoor digital signage. Featuring a 1073.78 × 201.335 mm ultra-wide active area, 4000:1 contrast ratio, and 3000 nits high brightness, it delivers exceptional sunlight readability and visual clarity.

The panel uses a 51-pin LVDS interface, supports 16.7M colors, and operates reliably in extreme environments from –20 ~ 70 °C. With a robust 3H hard-coated surface and a slim, durable structure, it is suitable for long-life applications requiring 24/7 operation.


Application Scenarios

This 43-inch high-brightness stretched LCD is ideal for:

• Passenger Information Display (PID)

Used in railways, buses, metros, and airport terminals for schedule boards, arrival messages, and dynamic advertising.

• Outdoor Digital Signage

Perfect for outdoor kiosks, bus shelters, EV charging stations, and fuel pumps where strong sunlight readability is essential.

• Retail & Wayfinding

Suitable for ultra-wide shelf displays, menu boards, directional signage, and smart store display systems.

• Industrial & Commercial Systems

Compatible with machine interfaces, control systems, and industrial automation requiring a high-reliability display.

Product FAQs

How bright is the RS430IVN-GD30?

It is rated at 3,000 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 43-inch panel, 4000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the RS430IVN-GD30 use?

It adopts 51 pins LVDS (2 ch, 8-bit) interface.

What is the power input requirement for the RS430IVN-GD30?

The power input requirement is 12V (Typ.).

What is the viewing angle?

The viewing angle is 89/89/89/89 (Typ.)(CR≥10).

Is the RS430IVN-GD30 suitable for outdoor or high-ambient-light use?

Yes. Rated at 3,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Hard coating (3H),.

What panel technology does the RS430IVN-GD30 use?

It uses a-Si TFT-LCD, LCM.
