Specifications
| Screen Diagonal | 48.5 inch |
| Brand | RisingStar |
| Model No | RS485IVN-GE08 |
| Active Area | 1209.6(H)*226.8(V) |
| Resolution | 1920*360 |
| Physical Size | 1221(H)*252.2(V)*33.5(D) |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio | 4000:1 |
| White Luminance ( Center ) | 500~5000 |
| Optical Response Time | 8 (Typ.)(G to G) ms |
| Nominal Input Voltage | 12.0V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [kg] | 4.47kgs |
| Interface Type | LVDS (2 ch, 8-bit), 51 pins |
| Support Color | 16.7M/1.07B |
| Surface Treatment | Matte (Haze 3%) |
| RoHS Compliance | RoHS Compliance |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS485IVN-GE08 is a 48.5-inch LCD display with 800 nits brightness, 1920×360 resolution and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

Specification
| Item | Specification |
|---|---|
| Screen Diagonal | 48.5 inch |
| Brand | RisingStar |
| Model No. | RS485IVN-GE08 |
| Active Area (mm) | 1209.6 (H) × 226.8 (V) |
| Resolution | 1920 × 360 |
| Physical Size (mm) | 1221 (H) × 252.2 (V) × 33.5 (D) |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio | 4000:1 |
| Brightness (cd/m²) | 500 ~ 5000 nits |
| Response Time | 8 ms (Typ., G→G) |
| Input Voltage | 12.0 V (Typ.) |
| Frame Rate | 60 Hz |
| Viewing Angle | 89/89/89/89 (CR ≥ 10) |
| Weight | 4.47 kg |
| Interface Type | LVDS (2-ch, 8-bit), 51-pin |
| Supported Colors | 16.7M / 1.07B |
| Surface Treatment | Matte (Haze 3%) |
| RoHS Compliance | Yes |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Description
The RisingStar RS485IVN-GE08, a 48.5-inch stretched-bar a-Si TFT-LCD module, is designed for professional and outdoor digital signage environments requiring long-duration, high-brightness visual performance. With an ultra-wide resolution of 1920×360, deep 4000:1 contrast, and industrial-grade brightness options reaching up to 800 nits, this model delivers exceptional clarity even under intense sunlight. The matte surface with Haze 3% reduces reflections, ensuring excellent readability in outdoor and semi-outdoor environments.
Built with an efficient 12V system, fast 8ms response, wide 178° viewing angles, and robust temperature endurance from -20 ~ 70 °C, the RS485IVN-GE08 is ideal for harsh or 24/7 operational conditions. LVDS 51-pin interface compatibility allows easy integration with industrial controllers, transportation systems, kiosks, and digital signage players.
Application Scenarios
This 48.5" high-brightness bar-type screen is widely used in:
• Transportation Passenger Information Systems
Railway platforms
Metro and subway stations
Bus terminals
Airport wayfinding and arrival boards
• Outdoor & Semi-Outdoor Digital Signage
EV charging stations
Fuel dispensers
Retail window-facing displays
QSR menu boards
Smart city information poles
• Industrial & Commercial Systems
Factory equipment HMI
Control room dashboards
Casino gaming and entertainment displays
The ultra-wide format, high brightness, and rugged design make it a reliable solution for environments requiring sunlight readability, continuous operation, and space-efficient visuals.
Product FAQs
How bright is the RS485IVN-GE08?
It is rated at 800 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 48.5-inch panel, 1920×360 resolution, 4000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS485IVN-GE08 use?
It adopts LVDS (2 ch, 8-bit), 51 pins interface.
What is the power input requirement for the RS485IVN-GE08?
The power input requirement is 12.0V (Typ.).
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10).
How is the screen surface treated?
The panel surface treatment is Matte (Haze 3%).
What panel technology does the RS485IVN-GE08 use?
It uses a-Si TFT-LCD, LCM.
