Specifications
| Screen Diagonal | 48.5 inch |
| RisingStar panel no | P485IVN01.1 |
| Model No | RS485ENT-GE20 |
| Active Area | 1209.6(W)×226.8(H) mm |
| Pixels | 1920(RGB)×360 40PPI |
| Physical Size | 1232.4(W)×249.6(H) ×29(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| White Luminance ( Center ) | 2000 cd/m2 (Typ.) [cd/m2 ] |
| Contrast Ratio | 4000:1 (Typ.) |
| Optical Response Time | 8 (Typ.)(G to G) |
| Nominal Input Voltage | 12V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down |
| Weight [g] | 4.47Kgs |
| Interface Type | LVDS (2 ch, 8-bit), 51 pins Connector |
| Support Color | 16.7M 72% NTSC |
| Surface Treatment | Antiglare (Haze 28%), Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS485ENT-GE20 is a 48.5-inch LCD display with 2,000 nits brightness and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
48.5 inch hi-tni TFT LCD, 2000 nits LED Backlight , 1920x360 ultra-wide aspect ratio 16:3
48.5 inch Stretched LCD
Ultra-Wide Screen (16 : 3)
High Brightness 3000 nits
LED Backlight
LCD blacking defect free (Hi-Tni 110 ˚C)
Low Power Consumption
P485IVN01.0 48.5 inch hi-tni tft lcd stretched bar display 1920*360 resolution, 4000:1 contrast ratio, LVDS interface, 89/89/89/89 wide viewing angle, 2000 nits high brightness, it is with an integral WLED backlight system, With LED Driver, without touch screen.
The operating temperature range of-20 ~ 70°C , a storage temperature range of -30 ~ 80°C , Landscape / Portrait, WLED Backlight, Life ≥ 70K hours. The stretched Bar display is with advanced wide temperature LC (-20-110°C), it features the wide temperature, hi- tni stretched bar panel. Based on its features, it is ideal to be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc.
With RisingStar customized brightness, it supports sunlight readable with dimming for smooth implementation in a wide working temperature ranging -20°C to 110°C, to make sure its best operation in harsh environments and deliver real-time information to passengers
RisingStar high tni (110°c) liquid crystal panel
P280IVN01.1 1000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P286IVN01.1 1000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P294IVN01.1 1000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P366IVN01.1 1000 Adv. Hi-Tni LC (-40~110℃), w/o DB, high brightness
P370IVN02.210700 Adv. Hi-Tni LC (-40~110℃), AG28%, 70Khrs high brightness
P370IVN03.1 1500 Adv. Hi-Tni LC (-40~110℃), AG28%, 70Khrs high brightness
P370IVN04.1 2500 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P420IVN01.0 2000 H-Tni, AG44% 24 high brightness
P420IVN01.1 2000 Adv. Hi-Tni LC (-40~110℃), AG28%, -20~60 24 high brightness
P420IVN02.0 1500 H-Tni, AG44% 24 high brightness
P420IVN02.1 1500 Adv. Hi-Tni LC (-40~110℃), AG28%, -20~60 high brightness
P420IVN03.1 2500 Adv. Hi-Tni LC (-40~110℃), AG28% 24 high brightness
P420IVN03.2 2500 Adv. Hi-Tni LC (-40~110℃), AG28%, -20~60 high brightness
P430KVN01.0 2000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P483IVN02.0 2000 Adv. Hi-Tni LC (-40~110℃), Photo mask, 70Khrs high brightness
P485IVN01.1 2000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P439KVN01.0 2000 dv. Hi-Tni LC (-40~110℃), AG28% high brightness
P495IVN01.0 1500 Adv. Hi-Tni LC (-40~110℃), Photo mask, 70Khrs high brightness
P495IVN02.0 2500 Adv. Hi-Tni LC (-40~110℃), Photo mask, 70Khrs high brightness
P495IVN03.0 2000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P566KVN01.1 700 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P584KVN01.0 2000 Adv. Hi-Tni LC (-40~110℃), Photo mask high brightness
P586ZVN01.0 2000 Adv. Hi-Tni LC (-40~110℃), AG28% high brightness
P449SVN01.0 2000 Adv. Hi-Tni LC (-40~110℃), Photo mask, 70Khrs high brightness
P353KVN01.0 1500 Adv. Hi-Tni LC (-40~110℃), Photo mask high brightness
Product FAQs
How bright is the RS485ENT-GE20?
It is rated at 2,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 48.5-inch panel, 4000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS485ENT-GE20 use?
It adopts LVDS (2 ch, 8-bit), 51 pins Connector interface.
What is the power input requirement for the RS485ENT-GE20?
The power input requirement is 12V (Typ.).
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down.
Is the RS485ENT-GE20 suitable for outdoor or high-ambient-light use?
Yes. Rated at 2,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Antiglare (Haze 28%), Hard coating (3H).
What panel technology does the RS485ENT-GE20 use?
It uses a-Si TFT-LCD, LCM.
