Specifications
| Panel Brand | AUO |
| Panel Model | P320HVN07.0 |
| Panel Size | 32" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 102PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 698.4(W)×392.85(H) mm |
| Bezel Opening | 701.4(W)×395.85(H) mm |
| Outline Size | 721.2(W)×415.65(H) ×58.5(D) mm |
| Surface | Antiglare: (Haze 28%), Hard coating (3H) |
| Brightness | 2500 nits (Typ.) |
| Contrast Ratio | 4000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | IPS |
| Best View | Symmetry |
| Response Time | 8 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | WLED, 70K hours, With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 18.10Kgs (Typ.) |
| Application | Digital Signage Outdoor High |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins Connector |
| Storage Temperature | -30~80 °C |
P320HVN07.0 is a 32-inch LCD display with 2,500 nits brightness, 1920×1080 resolution and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
32-inch sunlight readable digital display screen on top of gas station pump. AUO P320HVN07.0 2500 cd/㎡, with automatic dimming function, specially designed for gas stations, the screen display is clearly visible in sunlight, 1920*1080 resolution, AUO industrial grade LCD panel, LVDS interface, compatible with Android, windows, display motherboard, widely used for gas stations, gas station digital equipment display, advertising, RisingStar focus on gas station digital display digital signage.
Product FAQs
How bright is the P320HVN07.0?
It is rated at 2,500 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 32-inch panel, 1920×1080 resolution, 4000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the P320HVN07.0 use?
It adopts LVDS (2 ch, 8-bit), 30 pins Connector interface.
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10).
Is the P320HVN07.0 suitable for outdoor or high-ambient-light use?
Yes. Rated at 2,500 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Antiglare: (Haze 28%), Hard coating (3H).
What panel technology does the P320HVN07.0 use?
It uses a-Si TFT-LCD, LCM.
