4000 Nits High Brightness Industrial Monitor LCD 86"

4000 Nits High Brightness Industrial Monitor LCD 86"

BrandRisingstar
Model nameRS860ENT-GD40
Screen size86 "
Screen typeOutdoor LCD Panel
Resolution3840(RGB)×2160
Brightness (cd/m²)4000
Overview Specifications Customized Services Support & Shipping

86" high brightness industrial LCD panel product features:

1. Use industrial-grade LCD panel.

2. Distributed LED backlight design

3. All-aluminum alloy structural design

4. Use industrial grade optical materials

5. Supports various brightness adjustment methods such as PWM, photoresistor, potentiometer, and DC.

6. Optional QLED display technology

7. Optional local dimming display technology

Application scenarios:

outdoor digital signage, flight passenger information display, airport digital advertising, bus station passenger information display, bus stop digital advertising, train station passenger information display, train station digital advertising, scenic spot information tour guide, golf event information display, Digital advertising for electric vehicle charging stations.

RS860ENT-GD40 86 inch high brightness display 86 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display

Manufacturer:      RisingSTAR                                         Model Name:     RS860ENT-GD40

Screen Size:          86 inch                                               Screen Type:       LCM ,   a-Si TFT-LCD

Pixel Number:      3840(RGB)×2160   (UHD)  51PPI       Arrangement:     RGB Vertical Stripe

Active Area(mm): 1895.04 × 1065.96 (H×V)                  Outline(mm):     1922.2 × 1093.2 × 43.3 (H×V×D)

Bezel Area(mm):  1897.0 × 1068.0 (H×V)                      Treatment:          Antiglare (Haze 3%), Hard coating (2H)

Luminance:          4000 cd/m² (Typ.)                              Contrast Ratio:   1200 : 1 (Typ.) (TM)

Viewing Angle:    89/89/89/89 (Typ.)(CR≥10)                Response:           8 (Typ.)(G to G) ms

Good View at:     Symmetry                                           Work Mode:        IPS, Normally Black, Transmissive

Color Depth:       16.7M/1.07B   71% NTSC                   Backlight:             WLED , 30K hours , With LED Driver

Mass:                  34.1/35.8Kgs (Typ./Max.)                    Used for:            Digital Signage Interactive Whiteboard

Refresh Rate:      120Hz                                                 Touchscreen:        Without

Signal Type:        V-by-One 16 lane , 97 pins Connector

Voltage Supply:  12.0V (Typ.)

Max. RatingsStorage Temperature: -30 ~ 105 °C    Operating Temperature: -20 ~ 70 °C

inventory_2

01 / Chassis & Materials

Structural integrity for extreme environments.

Enclosure Grade

Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel.

Protection Rating

Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10.

Surface Finish

Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting.

Format Architecture

Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations.

blur_on

02 / Optical & Display

Visibility optimization for extreme ambient lighting.

Luminance Output

Scalable 1500 - 5000 Nits with integrated Hi-Tni (110掳C) anti-blackening technology.

Optical Bonding

Full Vacuum Optical Bonding (OCR) - eliminates air gaps, fogging, and maximizes contrast ratio.

Advanced Coating

Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films.

settings_input_component

03 / Interface & I/O

Industrial signal and power regulation.

Connectors

Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB.

Power Regulation

Wide voltage DC 9V - 36V input with integrated surge and polarity protection.

Sensor Suite

Integrated ambient light sensors, thermal probes, and custom GPIO control protocols.

dns

04 / Embedded & Data

Software architecture and data sync.

Operating Systems

Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14.

Communication

High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet.

Sampling
10-15 Working Days
Standard
SUS316L / IP69K
Certifications
CE / FCC / UKCA
Response
8H Expert Team
verified

01 / Warranty Policy

Industry-leading protection for your investment.

Complete System

3 Years Full Warranty for the complete machine assembly.

LCD Module

1 Year Warranty for the original LCD assembly.

Extended Support

Optional extended warranty programs (up to 5 years) available upon request.

support_agent

02 / Field Support

Expert guidance throughout the product lifecycle.

Remote Assistance

24/7 technical support and configuration guidance via video link or remote access.

On-site Services

Local on-site installation and maintenance available for large-scale deployments.

schedule

03 / Production Timeline

Scalable manufacturing for urgent project schedules.

Sample Prototyping

Verification and custom prototype delivery within 10 Working Days.

Bulk Production

Standard bulk order fulfillment in 15 - 25 Working Days.

public

04 / Global Distribution

Reliable logistics via air, sea, or rail.

Express & Air

Door-to-door global delivery in 5 - 7 Working Days (DHL, FedEx, UPS).

Ocean & Rail

Cost-optimized bulk shipping in 30 - 45 Days for global major ports.
