Specifications
| Manufacturer | RisingSTAR |
| Model Name | RS860ENT-GD40 |
| Screen Size | 86 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 51PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1895.04 × 1065.96 (H×V) |
| Outline(mm) | 1922.2 × 1093.2 × 43.3 (H×V×D) |
| Bezel Area(mm) | 1897.0 × 1068.0 (H×V) |
| Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Luminance | 4000 nits (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.7M/1.07B 71% NTSC |
| Backlight | WLED, 30K hours, With LED Driver |
| Mass | 34.1/35.8Kgs (Typ./Max.) |
| Used for | Digital Signage Interactive Whiteboard |
| Refresh Rate | 120Hz |
| Touchscreen | Without |
| Signal Type | V-by-One 16 lane, 97 pins Connector |
| Operating Temperature | -20~70 °C |
RS860ENT-GD40 is a 86-inch LCD display with 4,000 nits brightness, 3840×2160 resolution and 1200:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
86" high brightness industrial LCD panel product features:
1. Use industrial-grade LCD panel.
2. Distributed LED backlight design
3. All-aluminum alloy structural design
4. Use industrial grade optical materials
5. Supports various brightness adjustment methods such as PWM, photoresistor, potentiometer, and DC.
6. Optional QLED display technology
7. Optional local dimming display technology
Application scenarios:
outdoor digital signage, flight passenger information display, airport digital advertising, bus station passenger information display, bus stop digital advertising, train station passenger information display, train station digital advertising, scenic spot information tour guide, golf event information display, Digital advertising for electric vehicle charging stations.
Product FAQs
How bright is the RS860ENT-GD40?
It is rated at 4,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 86-inch panel, 3840×2160 resolution, 1200:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS860ENT-GD40 use?
It adopts V-by-One 16 lane, 97 pins Connector interface.
What is the viewing angle?
The viewing angle is 89/89/89/89 (Typ.)(CR≥10).
Is the RS860ENT-GD40 suitable for outdoor or high-ambient-light use?
Yes. Rated at 4,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Antiglare (Haze 3%), Hard coating (2H).
What panel technology does the RS860ENT-GD40 use?
It uses LCM, a-Si TFT-LCD.
