2500 nits outdoor lcd panel 49 inch
OEM / ODM Manufacturer
Factory Direct
Order & Lead Time
Need 50+ units? for framework agreements.
Global Shipping Options
Samples ship in ~10 working days; Bulk orders in 15-25 working days.
- Express: DHL/FedEx door-to-door delivery (5-7 days)
- Sea Freight: Cost-optimized bulk shipping (30-45 days)
- Rush Orders: Available upon request for urgent projects
1-3 Year Standard Warranty
3 years for Display Units and 1 year for LCD modules. Extendable to 5 years. Includes 24/7 support, remote troubleshooting, and long-term spare parts availability.
All products are manufactured in our ISO 9001-certified facility.
CE, FCC, RoHS Certified
2500nits outdoor lcd panel 49 inch, sunshine readable,The outer frame is made of aluminum alloy, Low power consumption, Long service life .
Advantages of RisingLCD industrial-grade LCD module:
1. Adopt LG industrial-grade LCD panel;
2. Aluminum alloy structure design;
3, 120 degrees Celsius optical materials;
4. Matrix LED backlight design;
5, industrial-grade backlight driver motherboard;
6, automatic, knob, pwm and more brightness adjustment methods;
7, Support long-term supply system;
8 , 7-day fast response mechanism；
9, automatically dimming backlight driver motherboard.
Size | 49inch |
Panel item | RS490NET-N25 |
Panel type | a-Si TFT-LCD |
Display mode | IPS,Normally black，transmissive display |
Pixels | 1920*1080/3840*2160 |
brightness | 2500cd/m2 |
Constrast Ratio | 1200:1 |
Response Time | 6ms |
View angle | 89/89/89/89 (Min) |
View area | 1078.6*609.5mm(H*V) |
Dispaly area | 1076.9*607mm(H*V) |
Outline Size | 1106.4*641.6*47mm(H*V*D) |
Signal Type | LVDS |
Working freqyency | 60Hz |
Working temperature | -20℃ ~ 70℃ |
Storage Temperature | -30 ~ 80 °C |
Display ratio | 16:9 |
Display color | 16.7m/1.7B |
Backlight Voltage | 24V |
Backlight Power Consumption | 220w |
Surface Treatment | Haze 3%,Hard coating(2H) |
Weight | 17.28kgs |
01 / Chassis & Materials
Structural integrity for extreme environments.
| Enclosure Grade | Medical and Food grade SUS316L Stainless Steel, AL5052 Aluminum, or SECC Galvanized Steel. |
| Protection Rating | Certified IP65 / IP69K waterproof sealing. Mechanical impact protection rated at IK10. |
| Surface Finish | Industrial powder coating (RAL spectrum), sandblasting, and anti-acid marine painting. |
| Format Architecture | Chassis-mount, Open-frame, Panel-mount, and VESA-integrated configurations. |
03 / Interface & I/O
Industrial signal and power regulation.
| Connectors | Support for M12 Aviation Circular Connectors, DB9/RS232, and waterproof RJ45/USB. |
| Power Regulation | Wide voltage DC 9V - 36V input with integrated surge and polarity protection. |
| Sensor Suite | Integrated ambient light sensors, thermal probes, and custom GPIO control protocols. |
02 / Optical & Display
Visibility optimization for extreme ambient lighting.
| Luminance Output | Scalable 1500 - 5000 Nits with integrated Hi-Tni (110°C) anti-blackening technology. |
| Optical Bonding | Full Vacuum Optical Bonding (OCR) — eliminates air gaps, fogging, and maximizes contrast ratio. |
| Advanced Coating | Integrated AR (Anti-Reflective), AG (Anti-Glare), and AF (Anti-Fingerprint) nano-films. |
04 / Embedded & Data
Software architecture and data sync.
| Operating Systems | Full compatibility with Windows 7, 10/11 IoT; Linux support covering the last 3 generations (Ubuntu 20.04, 22.04, 24.04 LTS) and Debian; as well as comprehensive support for Android 11 through 14. |
| Communication | High-speed 4G/5G LTE modules, Dual-band Wi-Fi 6, and Gigabit Ethernet. |
