55” 4K UHD Window Digital Signage Display high brightness

55” 4K UHD Window Digital Signage Display high brightness

Panel BrandAUO
Panel NoT550QVN05.7 CELL
Screen size55"
Screen typeLCD Monitor
Resolution3840*2160
Brightness (cd/m²)3000
Overview Specifications Customized Services Support & Shipping

55” 4K UHD Window Digital Signage Display General Description

RS550ENT-N30 is a 55inch window digital signage display, that assembled with AUO high resolution 3840*2160 UHD, 80PPI original panel (T550QVN05.7 CELL), it well protected by with tempered glass and galvanized steel plate, After RisingLCD customized the backlight, it can achieve a great high brightness 3000nits, thanks to the high brightness, extra wide viewing angle 89/89/89/89, and built-in auto light sensor, intelligent thermal management, lower power consumption, this series 4K UHD window digital signage display is is widely used as adversting dsiplay for shop, retail, restaurant, bank, shopping mall and store,

T550QVN05

55” 4K UHD Window Digital Signage Display 4K Ultra HD

The 4K Ultra HD picture quality ensures great colour and rich details in all possible broadcasting surroundings, ranging from retail stores, to restaurants and office buildings.

With 3000 nits maximum brightness, this window digital signage display captive viewers with superior messaging clarity it make your content vividly stand out in any commercial location.

T550QVN05

Greater content visibility is achieved under a combination of high brightness, lower reflection. Ultra clear AG tempered glass of window digital signage display is in the front of the panel that removes the glass reflection, make the images in the display more richer and clearer under direct sunlight.

T550QVN05

OEM and ODM are welcomed!

RisingLCD is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, outside and inside digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingLCD is your best choice!

RS550ENT-N30 55 inch high brightness display 55 inch sunlight readable LCD High brightness display Sunlight readable display Outdoor waterproof display
Item NoRS550ENT-N30
Size55   inch
Panel BrandAUO
Panel NoT550QVN05.7 CELL
Display Area1209.6*680.4mm
Brightness3000nits
Resolution3840*2160   UHD 103PPI
Aspect Ratio16:09
Contrast4000:01:00
Response Time20   (Typ.)(G to G) ms
View Angle89/89/89/89   (Min.)(CR≥10)
LEDDLED
Lifetime50000H
Intelligent dimmingSupport
Intelligent temperature controlSupport
Remote ControlSupport
Input VoltageAC90-264V,50/60HZ
Shell MaterialMetal   Plate
Product Dimensions1254.5*725.4*89mm
Weight34KG
environmental conditionsSemi-outdoor
Operating temperature & humidity-20 ~ 70 °C
Main-boardAndroid   /PC/ HD Driver Board (Optional)
IO interfaceHDMI/VGA/DVI/USB/RJ45
