Specifications
| Parameter | Specification |
|---|---|
| Panel Size | 43" |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 51 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 940.896(W) × 529.254(H) mm |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating (3H) |
| Brightness | 2000~5000 nits |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° (Typ., CR≥10) L/R/U/D |
| Operating Mode | ADS, Normally Black, Transmissive |
| Panel Series | IPS Hard Panels: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich VA Soft Panels: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Viewing Direction | Full Angle |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 16.7M, 72% NTSC |
| Backlight Type | WLED, 30,000 hours, with LED driver |
| Refresh Rate | 60Hz 120Hz (60Hz input, built-in MEMC) 120Hz+120Hz: 120Hz panel + 120Hz backlight 240Hz (60Hz input) |
| Panel Weight | 8.36 kg (Typ.) |
| Applications | Digital Signage, Advertising Displays, Public Information Screens |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Driving Voltage | 12.0V (Typ.) |
| Operating Environment | Operating: -20~70 °C; Storage: -30~80 °C |
RS430ENT-ND50 is a 43-inch LCD display with 5,000 nits brightness, 1920×1080 resolution and 1200:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
43" High Brightness LCD Display – All Models (RisingStar)
Normal Series (D Series)
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS430ENT-ND20 | 2000 | 1920 × 1080 / 3840 × 2160 |
| RS430ENT-ND25 | 2500 | 1920 × 1080 / 3840 × 2160 |
| RS430ENT-ND30 | 3000 | 1920 × 1080 / 3840 × 2160 |
| RS430ENT-ND35 | 3500 | 1920 × 1080 / 3840 × 2160 |
| RS430ENT-ND40 | 4000 | 1920 × 1080 / 3840 × 2160 |
| RS430ENT-ND45 | 4500 | 1920 × 1080 / 3840 × 2160 |
| RS430ENT-ND50 | 5000 | 1920 × 1080 / 3840 × 2160 |

| Parameter | Specification |
|---|---|
| Panel Size | 43" |
| Panel Type | a-Si TFT-LCD, LCD Module |
| Resolution | 1920 (RGB) × 1080, FHD, 51 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 940.896(W) × 529.254(H) mm |
| Viewable Area | - |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating (3H) |
| Brightness | 2000 ~ 5000 nits |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° (Typ., CR≥10) L/R/U/D |
| Operating Mode | ADS, Normally Black, Transmissive |
| Panel Series | IPS Hard Panels: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich VA Soft Panels: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Viewing Direction | Full Angle |
| Response Time | 8 ms (Typ., G to G) |
| Display Colors | 16.7M, 72% NTSC |
| Backlight Type | WLED, 30,000 hours, with LED driver |
| Refresh Rate | 60Hz 120Hz (60Hz input, built-in MEMC) 120Hz+120Hz: 120Hz panel + 120Hz backlight 240Hz (60Hz input) |
| Panel Weight | 8.36 kg (Typ.) |
| Applications | Digital Signage, Advertising Displays, Public Information Screens |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Driving Voltage | 12.0V (Typ.) |
| Operating Environment | Operating: -20 ~ 70 °C; Storage: -20 ~ 70 °C |
Application Note:
This 43" high-brightness, wide-viewing-angle FHD panel is ideal for digital signage, storefront advertising, interactive kiosks, and public information displays, providing clear, vivid images even in bright ambient light.
Product FAQs
How bright is the RS430ENT-ND50?
It is rated at 5,000 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 43-inch panel, 1920×1080 resolution, 1200:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS430ENT-ND50 use?
It adopts LVDS (2 ch, 8-bit), 51 pins interface.
What is the power input requirement for the RS430ENT-ND50?
The power input requirement is 12.0V (Typ.).
What is the viewing angle?
The viewing angle is 89° / 89° / 89° / 89° (Typ., CR≥10) L/R/U/D.
Is the RS430ENT-ND50 suitable for outdoor or high-ambient-light use?
Yes. Rated at 5,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Anti-glare (Haze 1%), Hard Coating (3H).
What panel technology does the RS430ENT-ND50 use?
It uses a-Si TFT-LCD, LCD Module.
