Specifications

Size

15.6inch

Panel item

RS156NET-N10

Panel type

a-Si TFT-LCD

Display mode

 IPS,Normally black,transmissive display

Pixels

1366*768

brightness

1000cd/m2

Contrast Ratio

800:1

Response Time

3.8/1.2ms

Viewing Angle

80/80/80/80

View area

347.45*196.8mm(H*V)

Display Area

344.16*193.59mm(H*V)

Outline Size

370*217*9.8mm(H*V*D)

Signal Type

LVDS

Refresh Rate

60Hz

Operating Temperature

-20~70°C

Storage Temperature

-30~80 °C

Aspect Ratio

16:9

Display color

16.7m

Surface Treatment

Haze, Hard coating(3H)

Weight

1.35kgs

Shenzhen risingstar outdoor high light LCD Co., LTD., Using LED backlight special system, Not only more energy saving than the traditional CCFL backlight, Brightness is quite high. Bright highlights, Even brightness, Color saturation, Outdoor advanced color management solutions, Providing more detailed color management options, Side-entry lighting design, Brightness 500-1000 Nits (optional), brightness uniformity can reach more than 90%; High color saturation, Clear picture, Good picture quality,15.6 "LCD module with max brightness up to 1500nits, Vsible under sunlight brightness 500--1000nits (optional), Brightness uniformity can reach more than 90%; The color saturation is high, the picture is clear, and the picture quality is fine.

Product FAQs

How bright is the RS156ENT-N10?

It is rated at 1,000 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 15.6-inch panel.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the RS156ENT-N10 use?

It adopts LVDS interface.

What is the viewing angle?

The viewing angle is 80/80/80/80.

Is the RS156ENT-N10 suitable for outdoor or high-ambient-light use?

Yes. Rated at 1,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Haze, Hard coating(3H).

What panel technology does the RS156ENT-N10 use?

It uses a-Si TFT-LCD.
