Specifications

24.5" M250HTN01.8 TFT LCD Panel Module


Panel BrandRisingStar
Panel ItemM250HTN01.8
Size24.5 inch
Panel Typea-Si TFT-LCD, LCM
Resolution 1920*1080
Pixel FormatRGB Vertical   Stripe
Display Area543.744(W)*302.616(H)mm
Outline   Size 552.49*319.58(H)mm
Surface   Treatment Antiglare (Haze 25%), Hard Coating (3H)
Brightness500cd/m²
Contrast   Ratio.1000:1
Viewing Angle89/89/89/89(Min)
Display ModelAHVA, Normally Black, transmissive Display
Best View   on Symmetry
Response Time5 (Typ.)(G to G)
Display Color16.7M, 99% s RGB
Lamp Type17S4P WLED, 30K   hours, without Driver
Working   Frequency165Hz
Touch   Screen Without
Panel   Weight 1.71/1.80Kgs(Typ./Max)
Signal   Interface LVDS (4ch, 8-bit), 61   pins connector
Input   Voltage 12v(Typ.)
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C
Backlight   Voltage12V
Current   State: In Production

M250HAN01.8 is a 24.5-inch LCD display with 500 nits brightness, 1920×1080 resolution and 1000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

24.5 inch RisingStar M250HAN01.8 LCD Panel Module

High resolution LCDs from 1inch to 100 inch

RisingStar 24.5 inch highlight LCD screen, with 1920*1080 full high definition resolution, and 17S4P WLED , 30K hours working life, we use RisingStar liquid crystal module, and the higher brightness(400-1000 cd/m² is optional). original design, Stability highlight, Full size design, New original package display module structure and installation method thereof ,High flexibility, excellent heat dissipation and convenient maintenance.

We, one of the manufacture of high resolution screen enterprises in China, OEM and ODM are welcomed, we warmly welcome you to wholesale bulk cheap 24.5" RisingStar M250HAN01.8 LCD Panel with your customized request.

 M250HAN01.8 LCD Panel are widely used in industrial control displays, car custom screens, tankers, 4S shop, museum, exhition, library etc. All of these devices are special depend on the high bright.

Hot Tags: 24.5 inch a-si tft lcd module, China, factory, cheap, price, customized, quotation, window facing LCD, Outdoor Suspended Advertising Player,  Smart LCD Advertising Player,  transparent lcd panel, lcd splicing display

M250HAN01.8, M250HTN01.C, M250HAN02.2, M250HAN03.0,  M250HAN03.2, M250HAN01.A

Product FAQs

How bright is the M250HAN01.8?

It is rated at 500 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 24.5-inch panel, 1920×1080 resolution, 1000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the M250HAN01.8 use?

It adopts LVDS (4ch, 8-bit), 61 pins connector interface.

What is the power input requirement for the M250HAN01.8?

The power input requirement is 12v(Typ.).

What is the viewing angle?

The viewing angle is 89/89/89/89(Min).

How is the screen surface treated?

The panel surface treatment is Antiglare (Haze 25%), Hard Coating (3H).

What panel technology does the M250HAN01.8 use?

It uses a-Si TFT-LCD, LCM.
