Specifications

Item NoRS270ENT-N20
Panel BrandLG display
Panel ItemLM270WF7-SLD1
Size27 inch
Panel Typea-Si TFT-LCD, LCM
Resolution 1920(RGB)×1080, FHD, 81PPI
Pixel FormatRGB Vertical Stripe
Display Area597.888(W)×336.312(H) mm
Outline Size 611.5(W)×355.8(H) mm
Bezel Area601.5(W)×339.95(H) mm
Surface Treatment Antiglare,Hard coating (3H)
Brightness2000cd/m² RisingStar customized
Contrast Ratio.1000:1
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Display ModelIPS, Normally Black, Transmissive
Response Time14 (Typ.)(G to G)
Display Color16.7M, 72% NTSC
BacklightLVDS (2 ch, 8-bit), 30 pins Connector
Touch Screen Without
Panel Weight 2.87/3.01kgs (Typ./Max.)
Frame Rate60Hz
Input Voltage 5.0V(Typ.)
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C
Current State: In Production

RS270ENT-N20 is a 27-inch LCD display with 2,000 nits brightness, 1920×1080 resolution and 1000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

RisingStar RS270ENT-20 is a color active matrix TFT LCD panel using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 27 inch diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.

27 inch 2000nits high brightness LCD Panel Main Features:

LG original IPS LCD panel LM270WF7-SLD1

High resolution: 1920*1080

Brightness up to 2000 nits

Built-in Auto Light sensor

Wide View angle

Support 24 hours, 365days non-stop display

27 inch 2000nits high brightness LCD Panel adopts IPS technology

it does not produce image distortion and minimizes color shift when viewed from different angles, the IPS panel provides clear images and instantly optimizes screen color and brightness.

27 inch 2000nits high brightness LCD Panel

27 inch 2000nits high brightness LCD Panel with 2K Full HD resolution.

The 2K HD picture quality ensures great colour and rich details in all possible broadcasting, HD screen delicate presentation of fresh visual experience.

27 inch 2000nits high brightness LCD Panel built in Auto brightness control

Different external lighting condition requires different brightness leverls, an onboard light sensor that built-in LCD panel measures the ambient light in the area and automatically adjust the image light accordkingly, offer a best experience to the viewer, and also can save the engery cost, reduce the heat and extends the life of the screen.

'RS215ENT-N15 21

27 inch 2000nits high brightness LCD Panel with 2000nits high brightness

With the feature of 2000nits high brightness, clear resolution and rich depth, the LCD panel display could let you see a vivid world, this panel could make you see the real image even under the sun, it gives you a comfortable visual experience no matter what you are dong at any time.

RisingStar is a high-tech enterprise specilized in the research and development of outdoor high brightness LCD modules, with many years experience in the design and manufacturing and sales, we can offer you 10.1inch to 100inch LCD panel with brightness of 500nits to 5000nits according to the customers requests. OEM/ODM are all welcomed!

Product FAQs

  • It is rated at 2,000 nits (cd/m²) brightness.

  • It uses a 27-inch panel, 1920×1080 resolution, 1000:1 contrast ratio.

  • The operating temperature range is -20 °C to 70 °C.

  • Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

  • The power input requirement is 5.0V(Typ.).

  • The viewing angle is 89/89/89/89 (Typ.)(CR≥10).

  • Yes. Rated at 2,000 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

  • The panel surface treatment is Antiglare,Hard coating (3H).

  • It uses a-Si TFT-LCD, LCM.
