Specifications

37" RS370IVN-GD25 Outdoor Stretched Monitor


Panel BrandRisingStar
Panel ItemRS370IVN-GD25
Size37 inch
Panel Typea-Si TFT-LCD,   LCM
Resolution 1920(RGB)*540 54PPI
Pixel FormatRGB Vertical   Stripe
Display Area904.32*245.34(H*V)mm
Outline   Size 923.3*277.1*30.5(H*V*D)mm
Bezel Area907.5*257.5(H*V)mm
Surface Treatment Antiglare (Haze 28%), Hard Coating (3H)
Brightness2500cd/m²
Contrast   Ratio.4000:1
Viewing Angle89/89/89/89(Min)
Display ModelAMVA3, Normally   Black, transmissive Display
Best View   on Symmetry
Response Time5 (Typ.)(G to G)
Display Color16.7M/1.078  76% s RGB
BacklightWLED, 70K hours, With   LED Driver
Touch   Screen Without
Panel   Weight 4.59Kgs
Frame Rate60Hz
Signal   Interface LVDS (2ch, 8-bit), 51   pins connector
Input   Voltage 12v(Typ.)
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C
Current   State: In Production

RS370IVN-GD25 is a 37-inch LCD display with 2,500 nits brightness, 1920×540 resolution and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

RisingStar 37 inch high brightness stretch LCD bar provides 1920*540 ultra wide aspect ratios, 1500nits high brightness, can be clearly visible under direct sunlight, and give perfect visual performance in a wide public application, especially for the passenger information on the public transport scuh as train.metro station

RisingStar 37 inch stretched LCD displays are using the original factory open cell instead of the resizing or 'cut' LCD panels, whcih is the standard size, and reduces the risk of broken glass, micro cracks, and any light leakages.

37寸

Stretched bar LCD display is an innovative ultra-wide, sunlight readable LED backlight LCD display, it provides an LCD panel with specific rations for digital signage, public transportation, exhibition hall, department store, vending machine, POS and industrial applications, it is a high-quality full color video with energy-efficient.
Risingstar stretched LCD panel parameter

RisingStar high brightness stretch bar LCD display is with super-wide aspect ratios as wide as 16:1 and in sizes ranging 19inch, 24inch, 21 inch, 28inch, 37 inch,43.8inch, 48.5 inch, 58.4 inch, (customization sizes as you like), and with customized backlight, the brightness can achieve 3000nits, or even higher (more brightness are option, 1000nits, 1500nits, 2500nits, 3500nits, 4500nits, 5000nits, high brightness makes these screen can read even in the directly sunlight, ideal for passenger information display, transport timetables, traffic messages, announcements and other important communications.

Product FAQs

How bright is the RS370IVN-GD25?

It is rated at 2,500 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 37-inch panel, 1920×540 resolution, 4000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the RS370IVN-GD25 use?

It adopts LVDS (2ch, 8-bit), 51 pins connector interface.

What is the power input requirement for the RS370IVN-GD25?

The power input requirement is 12v(Typ.).

What is the viewing angle?

The viewing angle is 89/89/89/89(Min).

Is the RS370IVN-GD25 suitable for outdoor or high-ambient-light use?

Yes. Rated at 2,500 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Antiglare (Haze 28%), Hard Coating (3H).

What panel technology does the RS370IVN-GD25 use?

It uses a-Si TFT-LCD, LCM.
