Specifications

55" P550HVN06.4 High Brightness LCD  Display


Panel BrandRisingStar
Panel ItemP550HVN06.4
Size55 inch
Panel Typea-Si TFT-LCD,   LCM
Resolution 1920(RGB)*1080(FHD)   40PPI
Pixel FormatRGB Vertical   Stripe
Display Area1209.6*680.4(H*V)mm
Outline   Size 1235.6*706.4*58.2(H*V*D)mm
Bezel Area1216*686.8(H*V)mm
Surface   Treatment Reflection 1.45%   (Max.)
Brightness2500cd/m²
Constrast   Ratio.4000:1
Viewing Angle89/89/89/89(Min)
Display ModelAMVA3, Normally   Black, transmissive Display
Best View   on Symmetry
Response Time8 (Typ.)(G to G) ms
Display Color1.07B  72%    NTSC
BacklightWLED, 60K hours, With   LED Driver
Touch   Screen Without
Panel   Weight 15.0Kgs
Frame Rate60Hz
Signal   Interface LVDS (2ch, 8-bit), 51   pins connector
Input   Voltage 12v(Typ.)
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C
Current   State: In Production

P550HVN06.4 is a 55-inch LCD display with 2,500 nits brightness, 1920×1080 resolution and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

55" P550HVN06.4 High Brightness LCD Display

General Description:

P550HVN06.4 is 55 inch LCD high brightness display with 1920(RGB)*1080 resolution, and this display is equipmented with a direct-light source LED backlight. P550HVN06.4 adopts LVDS (2 ch, 10-bit) signal interface, 51 pins, which are connected by terminals, and the drive voltage is 12.0V (Typ.)

This display characterizes wtih a brightness of 2500 cd/m², a static contrast ratio of 4000:1 and an ability to work in the industrial temperature range (-20~70°C).

High brightness and contrast ratio are the main features of this monitor, it can work for a long time with wide range of temperatures, and could be read from any angle, no gray scale inversion effect due to the IPS/MVA technology. it is recommended successfully to be applied in transportation and automotive industry, govement lines, bus station etc.

P550HVN06

P550HVN06

OEM and ODM are welcomed!

RisingStar Advantage:

OEM/ODM is acceptale!

Small MOQ is acceptable!

Competitive price!

Fast Delivery time!

RisingStar is your best choice!

Ref no. P550HVN06.5, P550HVN09.1, T550QVN05.7 cell.

Hot Tags: sunlight screen 2500 nits lcd panel, China, factory, cheap, price, customized, quotation, window facing LCD, 3000 cd/m² LCD Display, 43 Charging Pile LCD Advertising Player, 75 Inches Highlight LCD, 1000 cd/m²s LCD Screen, 82 LCD E-Reader, 21.5 LCD Strip Screen

Product FAQs

How bright is the P550HVN06.4?

It is rated at 2,500 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 55-inch panel, 1920×1080 resolution, 4000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the P550HVN06.4 use?

It adopts LVDS (2ch, 8-bit), 51 pins connector interface.

What is the power input requirement for the P550HVN06.4?

The power input requirement is 12v(Typ.).

What is the viewing angle?

The viewing angle is 89/89/89/89(Min).

Is the P550HVN06.4 suitable for outdoor or high-ambient-light use?

Yes. Rated at 2,500 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Reflection 1.45% (Max.).

What panel technology does the P550HVN06.4 use?

It uses a-Si TFT-LCD, LCM.
