    BOE TDA150-005V01 15 inch high brightness outdoor TFT-LCD module
    • BOE TDA150-005V01 15 inch high brightness outdoor TFT-LCD module
    • BOE TDA150-005V01 15 inch high brightness outdoor TFT-LCD module
    • BOE TDA150-005V01 15 inch high brightness outdoor TFT-LCD module

    BOE TDA150-005V01 15 inch high brightness outdoor TFT-LCD module

    TDA150-005V01 is a 15.0-inch a-si TFT LCD module,

    Brand:

    BOE

    Model name:

    TDA150-005V01

    Screen size:

    15"

    Screen type:

    Outdoor LCD Monitor

    Resolution:

    1600(RGB)×1200

    Brightness (cd/m²):

    500


    *Name:
    *Country:
    *E-mail:
    Phone:
    *Content:

    TDA150-005V01 is a 15.0-inch LCD module with a-Si TFT-LCD technology. Its operating temperature is -20 ~ 70°C, and its storage temperature is -30 ~ 80°C. This model is suitable for industrial applications.


    The display resolution is 1600 (RGB) × 1200 (UXGA), and the pixels are arranged in RGB vertical stripes. Its display area size is 304.8×228.6 (width×height) mm, the appearance size is 317.4 (width)×242 (height) mm, the surface treatment is matte (Haze 25%), Hard coating (3H), the net weight of the product is 620g (Typ.). TDA150-005V01 adopts LVDS (2 ch, 8-bit) signal interface, a total of 40 pins, which are connected by terminals, and the drive voltage is 3.3V (Typ.).

    sunlight readable monitor





    outdoor lcd displaydirect sunlight readable LCD15 inch lcd screen

    Q:who are we?

    A:R-star originated from Shenzhen, China,  We are a professional manufacturer of high end highlight LCD, we can provide from 10.1 to 120 inch highlight TFT LCD modules, There are more than 100 employees, including 20 experienced engineers. The company has passed ISO9001/ISO14001/CCC/CE/FCC/ROHS/UL and other certifications, has a high-level R&D platform, and has become an ODM/OEM partner of many world-class companies.Our markets cover Asia, North America, Africa, Middle East, Europe, Central and South America and Oceania.We believe that if you give us a chance to serve, we will be your trusted supplier in China.


    Q:Are you manufacturer(factory)?

    A:Yes, we're. Also OEM/ODM service available here.Welcome to share your ideas with us. It's our pleasure to provide best solution for you.


    Q:how can we guarantee quality?

    A:Always final Inspection before shipment;


    Hot Tags: BOE TDA150-005V01 15 inch high brightness outdoor TFT-LCD module, manufacturers, suppliers, factory, Customized


    brandBOEModel nameTDA150-005V01
    size15 inchScreen typea-Si TFT-LCD,LCD module
    resolution ratio1600(RGB)×1200 [UXGA] 133PPIPixel configurationRGB vertical bar
    Display Area304.8×228.6mm (H×V)Surface treatmentFog surface(Haze 25%),Hard coating (3H)
    Brightness(cd/m²)500cd/m²(Typ.)or customizedContrast Ratio1000:1 (Typ.) (TM)
    Viewing Angle85/85/85/85 (Min.)(CR≥10)Outline dimension317.4 × 242 mm (H×V)
    Signal interfaceLVDS (2 ch, 8-bit) ,erminal, 40 pins

    work environmentStorage temperature: -30 to 80 °C  Operation Temperature: -20 to 70 °C



    The model parameters of the same size are as follows:

    brandBOEModel nameRT150X0M-N10
    size15 inchScreen typea-Si TFT-LCD,LCD module
    resolution ratio1024(RGB)×768, XGA, 85PPIPixel configurationRGB vertical bar
    Display Area304.8×228.6mm (H×V)Surface treatmentFog surface(Haze 25%),Hard coating (3H)
    Brightness(cd/m²)1100cd/m²(Typ.)or customizedContrast Ratio1000:1 (Typ.) (TM)
    Viewing Angle80/80/80/80 (Min.)(CR≥10)Outline dimension326.5×253.5(H×V)
    Signal interfaceLVDS (1 ch, 8-bit) ,erminal, 20 pins

    work environmentStorage temperature: -30 to 80 °C  Operation Temperature: -20 to 70 °C

    brandBOEModel nameDV150X0M-N16
    size15 inchScreen typea-Si TFT-LCD,LCD module
    resolution ratio1024(RGB)×768, XGA, 85PPIPixel configurationRGB vertical bar
    Display Area304.128×228.096(H×V) mmSurface treatmentFog surface(Haze 25%),Hard coating (3H)
    Brightness(cd/m²)600cd/m²(Typ.)or customizedContrast Ratio1000:1 (Typ.) (TM)
    Viewing Angle89/89/89/89(Min.)(CR≥10)Outline dimension326.5×253.5×9.7mm(H×V×D)
    Signal interface20 pins   LVDS (1 ch, 8-bit) , erminal

    work environmentStorage temperature: -30 to 80 °C  Operation Temperature: -20 to 70 °C

    brandBOEModel nameRV150U0M-N00
    size15 inchScreen typea-Si TFT-LCD,LCD module
    resolution ratio1600(RGB)×1200 [UXGA] 133PPIPixel configurationRGB vertical bar
    Display Area304.8 × 228.6 mm (H×V)Surface treatmentFog surface(Haze 25%),Hard coating (3H)
    Visual size307.2 × 231 mm (H×V)Contrast Ratio1000:1 (Typ.) (TM)
    Brightness(cd/m²)500cd/m²(Typ.)or customizedOutline dimension317.4×242 mm(H×V×D)
    Viewing Angle85/85/85/85(Min.)(CR≥10)

    Signal interfaceLVDS (2 ch, 8-bit),40 pins, erminal

    work environmentStorage temperature: -30 to 80 °C  Operation Temperature: -20 to 70 °C
