Specifications

46" P460HVN03.1 TFT LCD Panel   Module


Panel BrandRisingStar
Panel ItemP460HVN03.1
Size46 inch
Panel Typea-Si TFT-LCD,   LCM
Resolution 1920(RGB)*1080 (FHD)   47PPI
Pixel FormatRGB Vertical   Stripe
Display Area1018.08*572.67(H*V)mm
Outline   Size 1044.08*598.67(H*V*D)mm
Bezel Area1024.48*579.07(H*V)mm
Surface Treatment Antiglare (Haze 44%)
Brightness700cd/m²
Contrast   Ratio.4000:1
Viewing Angle89/89/89/89(Min)
Display ModelAMVA3, Normally   Black, transmissive Display
Best View   on Symmetry
Response Time6.5 (Typ.)(G+G)
Display Color16.7/1.07B 99%   Srgb
BacklightWLED, 50K hours, With   LED Driver
Touch   Screen Without
Panel   Weight 10.9Kgs (Typ.)
Frame Rate60Hz
Signal   Interface LVDS (2ch, 8-bit), 51   pins connector
Input   Voltage 12v(Typ.)
Operating Temperature-20~70 °C
Storage Temperature-30~80 °C
Current   State: In Production

P460HVN03.1 is a 46-inch LCD display with 700 nits brightness, 1920×1080 resolution and 4000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

46 inch P460HVN03.1 46 TFT LCD Panel Module ,

Orginal RisingStar P460HVN05.0 is a 46" diagonal a-Si TFT-LCD display panel,

It is with an integral WLED backlight system, With LED Driver, without touch screen.

It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.04G (10.3 m/s²). It's general features are summarized by Panelook in the following: Landscape / Portrait, Ultra High Brightness, WLED Backlight, Life ≥ 70K hours, With LED Driver, 8/10 bit, Matte , Circular POL. Based on its features, Panelook recommend that this model be applied to Digital Signage, Outdoor High Brightness etc.

OEM and ODM are welcomed!

Our Advantage:

OEM/ODM is acceptable

Small MOQ is acceptable

Competitive price

Quality is Guanteed

Quick Reply

package process 1

RisingStar is a professional highlight LCD manufacturer from China, specializes in manufacturing and distributing all types of LCD module, LCD monitors, outside and inside digital signage and goods are exported all of the world, could customize the products based on the customer needs with a competitive price, RisingStar is your best choice!

Product FAQs

How bright is the P460HVN03.1?

It is rated at 700 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 46-inch panel, 1920×1080 resolution, 4000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the P460HVN03.1 use?

It adopts LVDS (2ch, 8-bit), 51 pins connector interface.

What is the power input requirement for the P460HVN03.1?

The power input requirement is 12v(Typ.).

What is the viewing angle?

The viewing angle is 89/89/89/89(Min).

How is the screen surface treated?

The panel surface treatment is Antiglare (Haze 44%).

What panel technology does the P460HVN03.1 use?

It uses a-Si TFT-LCD, LCM.
