Specifications

Size

55inch

Panel type

a-Si TFT-LCD

View area

1214.2 × 685.0 mm (H×V)

Display Area

1209.6 × 680.4 mm (H×V)

Outline size

1232 × 708.9 × 28.6 mm (H×V×D)

Dispaly mode

IPS,Normally black,Transmissive

Drive-screen Voltage

12.V (Typ)

Resolution

3840*2160, WXGA

 Aspect Ratio

16:9

Display brightness

500- 5000cd/m2

Contrast Ratio

2000:1

 Viewing Angle

 89/89/89/89

 Display color

16.7M, 68% NTSC

Refresh Rate

60Hz

Surface Treatment

Haze, Hard coating(3H)

Light source type

WLED

Backlight lifetime

50000 hrs

RS550ENT-N25 is a 55-inch LCD display with 2,500 nits brightness, 3840×2160 resolution and 2000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.

55inch 2500nits high brightness lcd display module use LG brand. widely used in industrial control displays, electronic class cards, new energy charging piles, express cabinets, outdoor handheld control panels, car custom screens, tankers, etc. All of these devices are special depend on the high brightness.

Risingstar 55inch 3840*2160 lcd module ,Brightness 2500nits Outdoor High Light LCD Screen From China , LVDS,IPS, LCD Display Screen,The Brightness Can Be Customized.As one high resolution screen enterprises in China, we warmly welcome you to wholesale bulk cheap 55inch lcd module, high resolution screen made in China here and get quotation from our factory. All customized products are with high quality and competitive price.

UHD 4K 55 inch  sunlight readable  2500nitsLCD display module

Product FAQs

How bright is the RS550ENT-N25?

It is rated at 2,500 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 55-inch panel, 3840×2160 resolution, 2000:1 contrast ratio.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What is the power input requirement for the RS550ENT-N25?

The power input requirement is 12.V (Typ).

What is the viewing angle?

The viewing angle is 89/89/89/89.

Is the RS550ENT-N25 suitable for outdoor or high-ambient-light use?

Yes. Rated at 2,500 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.

How is the screen surface treated?

The panel surface treatment is Haze, Hard coating(3H).

What panel technology does the RS550ENT-N25 use?

It uses a-Si TFT-LCD.
