Specifications
| Item | Specification |
|---|---|
| Panel Size | 18.5 inches |
| Panel Type | a-Si TFT-LCD Module |
| Resolution | 1366 (RGB) × 768 (WXGA), 84 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 409.8 (W) × 230.4 (H) mm |
| View Area (Bezel Opening) | 413.4 (W) × 234.0 (H) mm |
| Surface Treatment | Anti-glare (Haze 13%), Hard Coating (3H) |
| Brightness | 500~1500 nits |
| Contrast Ratio | 1000:1 |
| Recommended Viewing | Full Viewing Angle |
| Response Time | 6 ms (Typ.) (G to G) |
| Viewing Angle (CR ≥10) | 89/89/89/89 (Left/Right/Up/Down) |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Panel Technology Notes | IPS Hard-Screen Series: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich; VA Series: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Supported Colors | 16.7M, 68% NTSC |
| Backlight Type | WLED, 50,000 hours lifetime, Built-in LED Driver |
| Weight | 1.04 / 1.10 kg (Typ./Max.) |
| Application Product | TV |
| Frame Rate | 60 Hz |
| High-Refresh Notes | 120 Hz (60 Hz input) with built-in MEMC; 120 Hz + 120 Hz (panel + backlight); 240 Hz (60 Hz input) |
| Interface | 30-pin LVDS (1 ch, 8-bit), Connector |
| Supply Voltage | 5.0 V (Typ.) |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS185ENT-GE15 is a 18.5-inch LCD display with 1,500 nits brightness, 1366×768 resolution and 1000:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
18.5" Industrial Ultra High Brightness LCD Display - All Models (RisingStar)
Industrial Series (E Series)
| Model No. | Brightness (nits) | Resolution |
|---|---|---|
| RS185ENT-GE05 | 500 | 1366×768 (WXGA), 84 PPI |
| RS185ENT-GE10 | 1000 | 1366×768 (WXGA), 84 PPI |
| RS185ENT-GE15 | 1500 | 1366×768 (WXGA), 84 PPI |

18.5-inch TFT-LCD Panel Specification
| Item | Specification |
|---|---|
| Panel Size | 18.5 inches |
| Panel Type | a-Si TFT-LCD Module |
| Resolution | 1366 (RGB) × 768 (WXGA), 84 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Display Area | 409.8 (W) × 230.4 (H) mm |
| View Area (Bezel Opening) | 413.4 (W) × 234.0 (H) mm |
| Surface Treatment | Anti-glare (Haze 13%), Hard Coating (3H) |
| Brightness | 500 ~ 1500 nits |
| Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
| Recommended Viewing | Full Viewing Angle |
| Response Time | 6 ms (Typ.) (G to G) |
| Viewing Angle (CR ≥10) | 89/89/89/89 (Left/Right/Up/Down) |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Panel Technology Notes | IPS Hard-Screen Series: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich; VA Series: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA |
| Supported Colors | 16.7M, 68% NTSC |
| Backlight Type | WLED, 50,000 hours lifetime, Built-in LED Driver |
| Weight | 1.04 / 1.10 kg (Typ./Max.) |
| Application Product | TV |
| Frame Rate | 60 Hz |
| High-Refresh Notes | 120 Hz (60 Hz input) with built-in MEMC; 120 Hz + 120 Hz (panel + backlight); 240 Hz (60 Hz input) |
| Interface | 30-pin LVDS (1 ch, 8-bit), Connector |
| Supply Voltage | 5.0 V (Typ.) |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Description & Application
This 18.5-inch a-Si TFT-LCD panel is designed for versatile display applications requiring wide viewing angles, stable image performance, and long-term reliability. Featuring an S-IPS “normally black” transmissive mode, the panel delivers consistent color accuracy and excellent contrast even under off-axis viewing—making it ideal for environments where screens are frequently viewed from multiple directions.
With brightness ranging from 500 to 1500 nits, the display supports both indoor and high-brightness outdoor-adapted use cases. Its anti-glare surface (13% haze) and 3H hard coating improve durability and readability, while the WLED backlight offers a 50,000-hour lifespan and integrates the LED driver for simplified system design.
The panel supports up to 120 Hz/240 Hz solutions with MEMC and high-speed backlight modulation, making it suitable for smoother motion display requirements such as gaming TVs, information kiosks, or multimedia screens. The wide operating temperature range (–20 to 70°C) enhances its suitability for industrial and semi-outdoor environments.
With a lightweight structure (1.04–1.10 kg), LVDS 30-pin interface, and robust IPS technology, this panel is commonly used in:
Consumer televisions
Information displays
Industrial monitors
Control panels
Advertising and signage displays
Embedded display systems
Product FAQs
How bright is the RS185ENT-GE15?
It is rated at 1,500 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 18.5-inch panel, 1366×768 resolution, 1000:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS185ENT-GE15 use?
It adopts 30-pin LVDS (1 ch, 8-bit), Connector interface.
What is the power input requirement for the RS185ENT-GE15?
The power input requirement is 5.0 V (Typ.).
What is the viewing angle?
The viewing angle is 89/89/89/89 (Left/Right/Up/Down).
Is the RS185ENT-GE15 suitable for outdoor or high-ambient-light use?
Yes. Rated at 1,500 nits, it is a high-brightness panel built for sunlight-readable and outdoor applications.
How is the screen surface treated?
The panel surface treatment is Anti-glare (Haze 13%), Hard Coating (3H).
What panel technology does the RS185ENT-GE15 use?
It uses a-Si TFT-LCD Module.
