Specifications

Display Panel Size 43 inch
Panel BrandLG/AUO/BOE
Display Area940.9*529.3 MM
Brightness 500 cd/m2
Resolution 1920*1080
Aspect Ratio 16:9
Contrast Ratio1200/1
Response Time8 (Typ.)(Tr/Td) ms
Viewing Angle89/89/89/89 (Min.)(CR≥10)
Backlight(DLED)
Life Hourup to up to 50,000 hoursours
Control SystemSmart DimmingSupport
Intelligent Temperature ControlSupport
Remote Control FunctionSupport
AV InputsVideoHDMI, VGA
Electrical ParametersInput VoltageAC110V/220V,50/60HZ
Maximum Power51W
ShellShell MaterialSheet Metal
Product Size1020*608.5*72mm
Weight 32.5kg
Shell Anti-Corrosion ProcessUse galvanized sheet + surface spray with special outdoor powder (outdoor anti-corrosion for more than 7 years).
Protection Glass Thickness 5mm AR tempered glass
Accessories IncludedAC Power Cable, Remote Control, Wall Mount
Operating EnvironmentOperating EnvironmentOutdoor IP66
Operating Ttemperature and Humidity-20-70°C/5%-95%RH
MultimediaMotherboard TypePC/HD Driver Board (optional)
IO interfaceHDMI/VGA/DVI
OptionAD BoardComputer Mother Board
Network TransmissionStandalone Mode、WIFI、3G、4G
Touch10 points touch, 20 points touch, Capacitive touch

RS430LNX01P01-BK is a 43-inch LCD display with 500 nits brightness and 1920×1080 resolution. Its operating temperature range is -20 °C to 70 °C.

RS430LNX01P01 is a 43 inch LCD display from Risingstar, which is a special product in our list, this display was modified from one of our classic product RS430MNX01D01, with lower brightness but higher grade water and dust proof.

In usually, Risingstar always focus on ultra high brightness LCD display and LCD panel, this low brightness indoor IP66 waterproof display is specially designed for the indoor environment with low ambient light also high humidity place, such like Aquarium and ship/yacht/boat.

Risingstar full waterproof indoor LCD display at aquarium

Depends on the lowe birghtness, RS430LNX01P01 only need 51W for power consumption, so you do not need worry about the consumption if mounting it on the boat, more information please searching on our website: www.risinglcd.com

Size (inch)

21.5

32

43

55

65

Model number

RS215MNX01D01

RS320MNX01D01

RS430LNX01P01

RS550MNX01D01

RS650MNX01D01

Brightness (cd/m2)

1000

1500

500

2000

3000

Resolution (pixels)

1920*1080

1920*1080

1920*1080

/3840*2160

1920*1080

/3840*2160

1920*1080

/3840*2160

Power (Watt)



51

265

300

Operating temperature

-20 ~ 70 °C

-20 ~ 70 °C

-20 ~ 70 °C

-20 ~ 70 °C

-20 ~ 70 °C

  • LCD panel: Risingstar has ability making our own design LCD panel, and we purchase A and A+ level Open-cell from LG, BOE, AUO and other famous liquid crystal glasses maker directly, this is the proof to make the high quality displays for each of our customers.

BOE, LG, AUO

  • Hosuing: The classic Risingstar display has full metal shells with matte black coating, this allowed the display has strength to afford and protect the vulnerable electroinc components from possibly impacts.

    back side of the 43-inch indoor IP66 waterproof LCD display

  • Electronic: Risingstar has customers from all over the world, EU, US, Asia...using the right plug and adapt different voltage is the basic issue we should figure out for our customers, you do not need worry about this; the possible OS for the display, we can offer both PC and Android to make you using easier; also the interfaces, HDMI/USB/VGA/DVI/DP/Type-C/RJ45 by your choice, our enegineer will help you found the most suitable motherboard.

    interfaces

43-inch window facing display series:

RS430MNX01D01, lower brightness but full waterproof indoor display, special product for low light environment such like Museum/Aquarium...

RS430MNX03D01, semi-outdoor and super slim design, the most highest integrated display we ever made...

RS430HNX02D05, much thincker and heavier type, but lower consumption and unique outer shell, all these for "Mute"...

Product FAQs

How bright is the RS430LNX01P01-BK?

It is rated at 500 nits (cd/m²) brightness.

What are the main display specifications?

It uses a 43-inch panel, 1920×1080 resolution.

What is the operating temperature range?

The operating temperature range is -20 °C to 70 °C.

Is this product available for OEM or ODM customization?

Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.

What interface does the RS430LNX01P01-BK use?

It adopts HDMI/VGA/DVI interface.

What is the power input requirement for the RS430LNX01P01-BK?

The power input requirement is AC110V/220V,50/60HZ.

What is the viewing angle?

The viewing angle is 89/89/89/89 (Min.)(CR≥10).
