Specifications
| Item | Specification |
|---|---|
| Panel Size | 43 inches |
| Panel Type | a-Si TFT-LCD, Liquid Crystal Module |
| Resolution | 1920 (RGB) × 1080 (FHD), 51 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 941.184 (W) × 529.416 (H) mm |
| Bezel Opening Area | 945.8 (W) × 534.02 (H) mm |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating (3H) |
| Brightness (Typ.) | 1000–5000 nits |
| Contrast Ratio (Typ.) | 1100:1 |
| Viewing Angle (Min.) | 89/89/89/89 (L/R/U/D) (CR ≥ 10) |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Wide Viewing Tech | Compatible with: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich |
| Response Time (Typ.) | 12 ms (Tr + Td) |
| Display Colors | 16.7M, 68% NTSC |
| Backlight Type | 2 strings WLED, 50,000 hours lifetime, Driver Not Included |
| Refresh Rate | 60Hz (Input) Optional: MEMC 120Hz, 120Hz+120Hz, 240Hz (Input 60Hz) |
| Touch Screen | Not Supported |
| Panel Weight | 7.50 kg (Typ.) |
| Application | Digital Signage |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins, Terminal |
| Driving Voltage | 12.0V (Typ.) |
| Operating Temperature | -20~70 °C |
| Storage Temperature | -30~80 °C |
RS43HJJ-NE07 is a 43-inch LCD display with 700 nits brightness, 1920×1080 resolution and 1100:1 contrast ratio. Its operating temperature range is -20 °C to 70 °C.
RS236HJJ-NE07 is 43 inch TFT LCD panel with 700 nits high brighness, 1920*1080 full HD resolution, 89/89/89/89 wide viewing angle, often used for any embedded systems, security and hand-held equipment which requires display in high quality.
RS236HJJ-NE07 high brightness main features:
1. High Brightness 700 nits
2. Sunlight Readable
3. 3000:1 high contrast ratio
4. Wide Viewing Angle of 178°(H), 178°(V)
5. Low Power Consumption
6. BL MTBF: 15,000 hours
RisingStar can offer the high brightness LCD screen from 10.1 inch to 110 inch, and brightness 700 nits, high brightness displays provide a vibrant and bright solution for embedded system, window advertising, traffic information, they are perfect for the outdoor digital signage application in airport, bus/train/raiway/ station and retail shop window.
43-Inch a-Si TFT-LCD Panel Specifications
| Item | Specification |
|---|---|
| Panel Size | 43 inches |
| Panel Type | a-Si TFT-LCD, Liquid Crystal Module |
| Resolution | 1920 (RGB) × 1080 (FHD), 51 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 941.184 (W) × 529.416 (H) mm |
| Bezel Opening Area | 945.8 (W) × 534.02 (H) mm |
| Surface Treatment | Anti-glare (Haze 1%), Hard Coating (3H) |
| Brightness (Typ.) | 1000–5000 nits |
| Contrast Ratio (Typ.) | 1100:1 (TM) |
| Viewing Angle (Min.) | 89/89/89/89 (L/R/U/D) (CR ≥ 10) |
| Display Mode | S-IPS, Normally Black, Transmissive |
| Wide Viewing Tech | Compatible with: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich |
| Response Time (Typ.) | 12 ms (Tr + Td) |
| Display Colors | 16.7M, 68% NTSC |
| Backlight Type | 2 strings WLED, 50,000 hours lifetime, Driver Not Included |
| Refresh Rate | 60Hz (Input) Optional: MEMC 120Hz, 120Hz+120Hz, 240Hz (Input 60Hz) |
| Touch Screen | Not Supported |
| Panel Weight | 7.50 kg (Typ.) |
| Application | Digital Signage |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins, Terminal |
| Driving Voltage | 12.0V (Typ.) |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Product FAQs
How bright is the RS43HJJ-NE07?
It is rated at 700 nits (cd/m²) brightness.
What are the main display specifications?
It uses a 43-inch panel, 1920×1080 resolution, 1100:1 contrast ratio.
What is the operating temperature range?
The operating temperature range is -20 °C to 70 °C.
Is this product available for OEM or ODM customization?
Yes. RisingStar is an OEM/ODM manufacturer and accepts customization requirements for volume orders; contact the sales team with your target specification.
What interface does the RS43HJJ-NE07 use?
It adopts LVDS (2 ch, 8-bit), 51 pins terminal interface.
What is the power input requirement for the RS43HJJ-NE07?
The power input requirement is 12.0V (Typ.).
What is the viewing angle?
The viewing angle is 89/89/89/89 (L/R/U/D) (CR ≥ 10).
How is the screen surface treated?
The panel surface treatment is Anti-glare (Haze 1%), Hard Coating (3H).
What panel technology does the RS43HJJ-NE07 use?
It uses a-Si TFT-LCD, Liquid Crystal Module.
